Запчасти Case IH 1110 (M-18) - FLARING TOOL, FOR USE WITH CURB LIFT

Service parts for hydraulic pressure relief line, for use with single acting hydraulic cylinder when connected to double acting auxiliary control valves used on I-2424, or I-444, I-2444 tractors equipped w/two auxiliary valves and front LH and RH hydraulic manifolding, unit A

1шт.

Service parts for hydraulic pressure relief line, for use with single acting hydraulic cylinder when connected to double acting auxiliary control valves used on I-424, I-2424, or I-444, I-2444 tractors equipped w/two auxiliary valves w/out hydraulic manifolding, unit B

1шт.

144034

ADAPTER,3/4" NPT Male x 1/2" NPT Fem

3/4 x 1/2 in. pipe reducing, unit A

1шт.

468256R1

CLAMP

HOSE, unit A

1шт.

479615R1

CONNECTOR, port, unit A, 2 for unit B

1шт.

395149R1

QUICK MALE COUPLING

COUPLING ASSY, self-sealing male, unit A

1шт.

395151R1

COUPLING

ASSY, self-sealing male, unit A

1шт.

141621

ELBOW,90 Degree, 3/4" NPT Street

3/4 in. 90 degree

2шт.

371357R91

ELBOW

W/LOCK NUT, adj, unit A, 2 for unit B

1шт.

HOSE ASSY, 18 inches long, unit A, discontinued for service

1шт.

HOSE ASSY, 28 inches long, 2 for unit B, discontinued for service

1шт.

586992R91

HYDRAULIC HOSE,0.50" ID x 48.00"

HOSE ASSY, 48 inches, unit A

1шт.

NLS

NO LONGER SERVICED

NIPPLE, 3/4 x 2-1/2 in. C-Z pipe

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32 in., 3 for unit A, 6 for unit B

1шт.

125988

TEE,3/4" NPT, Fem

3/4 pln pipe

1шт.

489611R92

TOOL ASSY.

KNIFE SECTION RIVETING TOOL PACKAGE, consists of Ref. nos. 3, 4 and 5

1шт.

55169C91

PACKAGE

LEDGER PLATE RIVETING TOOL PACKAGE, consists of Ref. nos. 1 and 2, for use with 489611R92

1шт.

1

489617R1

TOOL

flaring

1шт.

2

489616R1

TOOL

riveting

1шт.

3

489615R2

TOOL

rivet anvil

1шт.

4

489614R2

TOOL

heading

1шт.

5

HOLDER, riveting and flaring, order 489611R92

1шт.
