Запчасти Case IH 110 (C-19B) - HYDRAULIC EQUIPMENT

462755R1

ADAPTER, unit J

1шт.

60836H

BREATHER

unit J

1шт.

444033

ADAPTER

BUSHING, automotive pipe reducer, 1/2 to 1/4 in., 2 for unit A and B

1шт.

9402749

HYD CONNECTOR,7/8"-14, 37 Degree x 1/2"-14, Fem Pipe

CONNECTOR, 5/8 in. hydraulic 37 degree flared tube female pipe thd, for unit A and B

2шт.

9410204

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

CONNECTOR, 5/8 in. hydraulic 37 degree flared tube short swivel, unit F, G and H

1шт.

395149R1

QUICK MALE COUPLING

COUPLING, self sealing male, unit C through H

1шт.

461170R91

CYLINDER

ASSY, 2 x 8 in. single acting hydraulic, units B through H, built 1960 to 1966, order cylinder assy, 381832R93, for components see list of parts under details of hydraulic cylinder in section P

1шт.

381832R93

CYLINDER BLOCK

CYLINDER ASSY, 2 x 8 in. single acting hydraulic, units B through H, for components see list of parts under details of hydraulic cylinder in section P

1шт.

371291R95

CYLINDER

ASSY, 2-1/2 x 8 in. double acting hydraulic, units A and J, order cylinder assy, 145353C91, two adapters, 1252129C1 and two o-rings, 570828R1

1шт.

465050R91

CYLINDER

ASSY, 2 x 5 in. single acting hydraulic, units B through H, for components see list of parts under details of hydraulic cylinder in section P

1шт.

664580R91

HOSE

hydraulic, 42 in. long, unit C

1шт.

586992R91

HYDRAULIC HOSE,0.50" ID x 48.00"

HOSE, hydraulic, 48 in. long, unit D

1шт.

371415R92

HOSE, hydraulic, 57 in. long, unit E

1шт.

653319R91

HOSE, hydraulic, 40 in. long, unit F

1шт.

653318R91

HOSE

hydraulic, 34 in. long, unit G

1шт.

653320R91

HOSE

hydraulic, 66 in. long, unit H

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32 in., 3 for unit A through H

1шт.

526251R91

UNION

RESTRICTOR WITH 1/16 IN. ORIFICE

1шт.
