Запчасти Case IH 110 (C-19A) - HYDRAULIC EQUIPMENT, FOR USE WITH CHECK VALVE

9409275

CONNECTOR, 1/2 in. dry seal male to 7/8NF straight, unit C

1шт.

9402749

HYD CONNECTOR,7/8"-14, 37 Degree x 1/2"-14, Fem Pipe

CONNECTOR, 1/2 in. dry seal female to 7/8UNF straight, unit C

1шт.

9410204

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

CONNECTOR, 7/8-14 male to 7/8-14 male, 2 used with unit A

1шт.

395149R1

QUICK MALE COUPLING

COUPLING, 7/8-14 straight-thd self-sealing male, 2 used with unit A and B

1шт.

9410978

ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, O-Ring

W/BACK UP WASHER AND NUT, 90 degree adjustable, unit A and B

1шт.

9410282

ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw

90 degree female swivel, unit C

1шт.

466804R91

HOSE ASSY, 1/2 x 19 in. w/90 degree elbow, 5 used with unit A

1шт.

653337R91

HOSE ASSY, 1/2 x 49 in. w/90 degree elbow, unit A and B

1шт.

372842R91

HOSE ASSY, 1/2 x 24-3/8 in. w/90 degree elbow, 5 used with unit B, used with unit C

1шт.

653318R91

HOSE

ASSY, 1/2 x 34 in. w/90 degree elbow, unit C

1шт.

467051R91

HOSE ASSY.

HOSE ASSY, 1/2 x 24 in. male straight to female swivel, unit C

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32 in., 3 used with unit C, 6 used with unit A and B

1шт.

NUT, 5/8 in. C-Z, unit C

1шт.

NUT, 3/4 in. C-Z, 2 used with unit A and B

1шт.

SCREW, 5/8 x 3 in. C-Z cap, unit C

1шт.

SCREW, 3/4 x 3 in. C-Z cap, 2 used with unit A and B

1шт.

WASHER, 5/8 in. C-Z lock, unit C

1шт.

WASHER, 3/4 in. C-Z lock, 2 used with unit A and B

1шт.
