Запчасти Case IH 110 (C-17) - HYDRAULIC EQUIPMENT, FOR CURB LIFT

444015

ADAPTER, steel automotive pipe reducer, 3/8 in. to 1/4 in., 1 used for unit F

1шт.

444017

BUSHING

ADAPTER, steel automotive pipe reducer, 1/2 in. to 3/8 in., 1 used for unit F

1шт.

372413R91

CONNECTOR, ELEC

ADAPTER, 1/2 in. male pipe to 7/8 in. unf female straight, 1 used for unit B, 2 used for unit E

1шт.

444033

ADAPTER

BUSHING, automotive pipe reducer, 1/2 in. to 1/4 in. 3 used for unit F

1шт.

9410204

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

CONNECTOR, 5/8 in. hydraulic 37 degree flared short swivel, 2 used for unit C

1шт.

9402749

HYD CONNECTOR,7/8"-14, 37 Degree x 1/2"-14, Fem Pipe

CONNECTOR, 5/8 in. hydraulic 37 degree flared tube female pipe thd, 3 used for unit F

1шт.

9402710

HYD CONNECTOR,7/8"-14, 37 Degree x 1/2"-14, NPTF

CONNECTOR, 5/8 in. hydraulic 37 degree flared tube, 1 used for unit A

1шт.

395149R1

QUICK MALE COUPLING

COUPLING, str thd self-sealing male ball, 2 used for unit C and D

1шт.

395151R1

COUPLING

pipe thd self-sealing ball, 1 used for unit A

1шт.

381832R93

CYLINDER BLOCK

CYLINDER ASSY, 2 x 8 in. single acting hydraulic, 2 for units A and B, 1 for units C, D, E, F and G, for components see list of parts under details of hydraulic cylinder in section P

1шт.

371291R95

CYLINDER

ASSY, 2-1/2 x 8 in. double acting hydraulic, units E and F, order cylinder assy, 145353C91 two adapters, 1252129C1 and two o-rings, 570828R1

1шт.

465050R91

CYLINDER

ASSY, 2 x 5 in. single acting hydraulic, units C, D and G, for components see list of parts under details of hydraulic cylinder in section P

1шт.

454097

ELBOW

forged automotive steel, 1/4 in. pipe 45 degree street, 1 used for unit F

1шт.

454099

ELBOW,45 Degree, 1/2"-14 Female x 1/2"-14 Male

forged automotive steel, 1/2 in. pipe 45 degree street, 1 used for unit F

1шт.

9410282

ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, 37 Degree Fem Sw

5/8 in. hydraulic 37 degree flared tube 90 degree swivel, 1 used for unit B

1шт.

454111

ELBOW, automotive 1/2 in. pipe 90 degree street, 1 used for unit B

1шт.

9410978

ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, O-Ring

5/8 in. hydraulic 37 degree flared tube adjustable 90 degree, 1 used for units B and D, 2 used for unit G

1шт.

9402866

ELBOW,90 Degree, 7/8"-14, 37 Degree x 1/2"-14, NPTF

5/8 in. hydraulic 37 degree flared tube 90 degree, 1 used for unit E

1шт.

371357R91

ELBOW

7/8 in. hydraulic 37 degree flared tube 90 degree, 1 used for unit C

1шт.

653319R91

HOSE ASSEMBLY, 1/2 ID x 40 in. w/90 degree elbow, 1 used for unit D

1шт.

586992R91

HYDRAULIC HOSE,0.50" ID x 48.00"

HOSE ASSEMBLY, 1/2 ID x 48 in. w/90 degree elbow, 1 used for unit D

1шт.

653337R91

HOSE ASSEMBLY, 1/2 ID x 49 in. w/90 degree elbow, 2 used for unit A and G, 1 used for unit F

1шт.

653320R91

HOSE

ASSEMBLY, 1/2 ID x 66 in. w/90 degree elbow, 1 used for unit E, 2 used for unit B

1шт.

371415R92

HOSE ASSEMBLY, 1/2 ID x 57 in. w/90 degree elbow, 2 used for unit E

1шт.

653338R91

HOSE ASSEMBLY, 1/2 ID x 76 in. w/90 degree elbow, 2 used for unit C

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32 in., 3 used for unit A, 4 used for units B, D and F, 6 used for units C, E and G

1шт.

526251R91

UNION

RESTRICTOR, with 1/16 in. orifice, 1 for units A, B, E and F

1шт.

15203K

SPACER, hinge shaft, 1 used for units C, D and G

1шт.

454135

TEE, forged automotive steel, 1/2 in. pipe, 1 used for units A, B and F

1шт.

463577R92

VALVE, needle, 1 used for units A, B and F

1шт.

604683R1

HEADED PIN,1" x 4 1/2"

PIN, dld-std-hd 1 x 4-1/2 in.

1шт.

32-1632

COTTER PIN,1/4" x 2"

PIN, SPLIT (COTTER), 1/4" x 2"

1шт.

557283R1

WASHER

1-1/32 x 2-1/2 in. x 11 ga

2шт.
