Запчасти Case IH 1000 (K-17[B]) - HYDRAULIC EQUIPMENT / PRODUCT GRAPHICS

371291R95

CYLINDER

ASSY, 2-1/2 x 8 in. double acting hydraulic, order cylinder assy, 145353C91, two adapters, 1252129C1 and two o-rings 570828R1, for components see list of parts under details of hydraulic cylinders in section P

1шт.

371292R94

CYLINDER

ASSY, 3-1/2 x 8 in. double acting hydraulic, order cylinder assy, 1263474C91 two adapters, 1252129C1 and two o-rings 570828R1, for components see list of parts under details of hydraulic cylinders in section P

1шт.

381832R93

CYLINDER BLOCK

CYLINDER ASSY, 2 x 8 in. single acting hydraulic, for components see list of parts under details of hydraulic cylinder in section P

1шт.

653338R91

HOSE W/ONE 90 DEGREE ELBOW, 1/2 x 76 in.

1шт.

395149R1

QUICK MALE COUPLING

COUPLING ASSY, 7/8-14 str self-sealing male

1шт.

9402788

UNION,7/8"-14, 37 Degree x 7/8"-14, 37 Degree

7/8-14 C-Z 37 degree hyd flard tube

1шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32

3шт.

60836H

BREATHER

for 2-1/2 x 8 or 3-1/2 x 8 double acting cylinders

1шт.

491396R92

KIT

PACKAGE, product graphics, consists of: Product Graphics Listed Below

1шт.

PRODUCT GRAPHIC, 540 PTO operation

1шт.

NSS

NOT SOLD SEPARAT

PRODUCT GRAPHIC, operating instructions

1шт.

NSS

NOT SOLD SEPARAT

PRODUCT GRAPHIC, grease instructions

2шт.

61907C1

DECAL

PRODUCT GRAPHIC, caution, general warning

1шт.

64553C2

PRODUCT GRAPHIC

warning, power drive

1шт.

202707C2

PRODUCT GRAPHIC

caution, keep shields in place

1шт.

2753927R1

PRODUCT GRAPHIC, knuckle instructions

1шт.

77583C91

PACKAGE

IH trademark, large size, consists of (2) IH trademark 6.58x7.09 (NSS), (2) IH trademark 7.68x8.27 (NSS), (2) IH trademark 10.24x11.02 (NSS)

1шт.

77582C91

PACKAGE

IH trademark, medium size, consists of (2) IH trademark 3.66x3.94 (NSS), (2) IH trademark 4.39x4.72 (NSS), (2) IH trademark 5.48x5.91 (NSS)

1шт.

77581C91

PRODUCT GRAPHIC

PACKAGE, IH trademark, small size, consists of (2) IH trademark 1.46x1.57 (NSS), (2) IH trademark 2.19x2.36 (NSS), (2) IH trademark 2.93x3.15 (NSS)

1шт.

547495R92

DECAL KIT

PACKAGE, International name product graphics

1шт.

547497R92

DECAL

PACKAGE, model designation product graphics

1шт.
