Запчасти Case IH MDX41 (K.20[3]) - KIT, SWATHBOARD AND SPRING, 6 DISC K - Crop Processing

2

84307424

REINFORCEMENT

See Fig. K.10.E.60 (03B) Ref. 28

1шт.

3

84195596

SUPPORT

1шт.

4

84307425

SUPPORT

See Fig. K.10.E.60 (03B) Ref. 35

1шт.

5

84307423

BOARD

Swath, See Fig. F.20.C (3A)

1шт.

6

84195597

WASHER

1шт.

7

84195594

SPRING

1шт.

8

84195598

PLUG

1шт.

9

700712401

SCREW

3шт.

10

86500689

NUT,M10 x 1.5, Cl 10

3шт.

11

380424

NUT,M20 x 2.5, Cl 8

1шт.

12

628-12035

BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd

1шт.

13

100038

NUT,M12 x 1.75, Cl 8

1шт.

14

86511099

HEX SOC SCREW,M12 x 50mm, Cl 12.9, Full Thd

3шт.

15

337475

NUT,M12, Cl 10

3шт.

16

87360262

SPACER

1шт.
