(8-08) - HYDRAULIC CYLINDER MASTER, LEFT, 2-3/4" DIAMETER X 8" STROKE, S/N CFH0041501 - CFH0041987

Запчасти Case IH 8340 (8-08) - HYDRAULIC CYLINDER MASTER, LEFT, 2-3/4" DIAMETER X 8" STROKE, S/N CFH0041501 - CFH0041987 (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH 8340 - (8-08) - HYDRAULIC CYLINDER MASTER, LEFT, 2-3/4" DIAMETER X 8" STROKE, S/N CFH0041501 - CFH0041987 (35) - HYDRAULIC SYSTEMS
1
2
3
6
4
5
7
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

700707694

CYLINDER

HYDRAULIC CYLINDER COMPLETE

1шт.

1

700700094

CYLINDER

PISTON - cylinder

1шт.

2

700712100

SLEEVE CYLINDER

BARREL

1шт.

3

700700097

HEAD

- cylinder

1шт.

4

700710243

SLEEVE CYLINDER

ROD - piston

1шт.

5

700712119

BEARING

- cylinder rod

1шт.

6

102908A1

END

CLEVIS - rod end

1шт.

7

700700098

SEAL KIT

KIT

1шт.

Выбрано товаров: 8
