Запчасти Case IH 816 (G-34) - HYDRAULIC CYLINDERS AND CONNECTIONS

371291R95

CYLINDER

ASSY, 2-1/2 x 8 in. double acting hydraulic, unit A, order cylinders assy, 145353C91, two adapters, 1252129C1 and two o-rings, 570828R1, for components see list of parts under details of hydraulic cylinders in section P

1шт.

371292R94

CYLINDER

ASSY, 3-1/2 x 8 in. double acting hydraulic, unit A, order cylinder assy, 1263474C91 two adapters, 1252129C1 and two o-rings, 570828R1, for components see list of parts under details of hydraulic cylinders in section P

1шт.

395149R1

QUICK MALE COUPLING

COUPLING, self-sealing

2шт.

372570R91

HOSE ASSY.

HOSE, 1/2 x 152 in.

2шт.

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

3/4 x 15/16 x 3/32

4шт.
