Запчасти Case IH 816 (G-25) - KNIFE DRIVE CONVERSION

1

458973R4

PIN,25.41mm OD x 77.72mm L

knife

1шт.

2

219-31

LUBE NIPPLE,30 Degree Elbow, 1/8" - 27 NPTF

FITTING, 1/8-27 ptf 30 deg angle lub

1шт.

3

493199R11

SWAYBAR ASSY

1шт.

181707

BOLT,Hex, 1/2" - 20 x 2 1/4", Gr 5

SCREW, 1/2-13 x 2-1/4 znd hex-hd cap

1шт.

493-41052

LOCK WASHER,Ext Tooth, 1/2"

WASHER, 1/2 ext-tooth lock

2шт.

120371

NUT,1/2"-20, G5

1/2-13 C-Z hex.

1шт.

4

16964R91

FITTING

1/4-28 90 deg angle lub

1шт.

5

487307R1

BUSHING

3шт.

6

493853R1

BRACKET ASSY, pivot

1шт.

485734R1

CARRIAGE BOLT,Short NK, 1/2"-13 x 1 1/4", G5, Full Thd

BOLT, 1/2 x 1-1/4 znd sq-nk crg

4шт.

487374R1

BEARING LOCK NUT,Flg, USR, 1/2"-13

1/2-13 C-Z flange lock

4шт.

7

493201R1

BOLT, pivot

1шт.

22266R1

WASHER

1-5/32 x 1-3/4 x 22 ga C-Z, or as required

8шт.

427637

SLOTTED NUT,3/4"-10, G5

NUT, 5/8-11 slt hex. C-Z

1шт.

137204

COTTER PIN,1/8" x 1 1/2"

PIN, SPLIT (COTTER), 1/8" x 1 1/2"

1шт.

8

493202R1

BRACE ASSY, swaybar

1шт.

180175

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

SCREW, 1/2-13 x 1-1/4 znd hex-hd cap

1шт.

178591

LOCK WASHER,Ext-Int Tooth, 1/2"

WASHER, 1/2 int-ext tooth lock C-Z

1шт.

487374R1

BEARING LOCK NUT,Flg, USR, 1/2"-13

1/2-13 C-Z flange lock

1шт.

180179

BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5

SCREW, 1/2-13 x 1-3/4 znd hex-hd cap

2шт.

20869R1

WASHER

17/32 x 7/8 x 16 ga C-Z

7шт.

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

6шт.

9

493206R1

BALL AND SOCKET

1шт.

10

105465HA

FITTING, 1/8-27 ptf str lub 1/8"-27 NPT x .86" lg

1шт.

11

493207R1

TURNBUCKLE

1шт.

425-1310

SLOTTED NUT,5/8"-18, G5

NUT, 5/8-18 C-Z slt hex.

1шт.

87395

COTTER PIN,1/8" OD x 1-1/4" OAL

PIN, SPLIT (COTTER), 1/8" x 1-1/4"

1шт.

374061R1

JAM NUT

1-16 LH thd hex. jam

1шт.

12

493208R11

LINK ASSY, pivot

1шт.

374062R1

JAM NUT

NUT, 1-16 RH thd hex. jam

1шт.
