1
263117
CABLE TIE,292.1mm L, Nylon, Black
CABLE STRAP
5шт.
2
86539890
HOSE
1шт.
3
330346
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
1шт.
4
86539891
HOSE
1шт.
5
87515542
CYLINDER,Double Acting, 38.1mm Rod, 484.38mm Stroke
Swing, Monarch
1шт.
87515542R
REMAN-HYD CYLINDER
DC162 (10/08-)
1шт.
87515542C
CORE-HYD CYLINDER
Return Number
1шт.
7
86568174
WASHER
Nylon, M8
1шт.
8
86535159
ARM
SMV Spade Mount
1шт.
9
86547710
EMBLEM
KIT SMV Emblem
1шт.
10
86603686
PIN,25.4mm OD x 90mm L
2шт.
11
87055692
FRAME ASSY
1шт.
12
NS
NOT SERVICED
Serial Number Plate
1шт.
13
86598785
SELF-TAP SCREW
Rd Hd, Stainless Steel, #4 x 1/4"
2шт.
14
86506511
ADJUSTMENT ROD
2шт.
15
86627125
COTTER PIN,0.148" OD x 2.75" OAL, Internal
Hair
2шт.
16
86627020
SHIELD
Left Hand (Not Shown)
1шт.
16
86627018
SHIELD
Right Hand (Shown)
1шт.
17
9626558
FLANGE NUT,Flg, 1/4"-20
4шт.
18
86545693
COLLAR
2шт.
19
86547781
REFLECTOR,RED
Tape, Red, Retroreflective
1шт.
20
86574272
ANGLE
1шт.
21
86539892
HOSE,9.65 mm ID x 1003.3 mm
1шт.
22
86510725
WASHER
6шт.
23
86627704
PLATE
1шт.
25
84821
SCREW,Truss HD, #10 - 24 x 1/2"
2шт.
26
88959
BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 5
2шт.
28
86521614
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
3шт.
29
80684
LOCK WASHER,4.9mm ID x 8.48mm OD x 1.19mm Thk
2шт.
30
87364
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
2шт.
31
87340
LOCK WASHER,Helical Spring, 0.759" ID, CST, ZND
1шт.
32
86513238
LOCK WASHER,.515” ID x 1.070” OD x .120” TK
Belleville
3шт.
33
87304
NUT,#10-24
2шт.
34
86521609
FLANGE NUT,Flg, 3/8"-16
4шт.
35
394818
COTTER PIN,M5 x 25
2шт.
36
103060
BUSHING,9.85mm ID x 15.95mm OD x 7.1mm Thk
Roller
2шт.
37
285072
WASHER,10.3mm ID x 22.2mm OD x 2.7mm Thk
(3/8")
2шт.
38
86521613
BOLT,Hex, 3/8" - 16 x 1", Gr 5
2шт.
39
9706689
BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5
1шт.
40
140045
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
2шт.
41
88902
NUT,3/8"-16
1шт.
42
76344
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
1шт.
43
38027
BRACKET
SMV (Welded on)
1шт.
44
86613674
CASE
Manual
1шт.
45
88715
CARRIAGE BOLT,Sq Nk, 1/4" - 20 x 1/2", Gr 5, Full Thd
4шт.
46
9617873
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
2шт.
47
86547711
DECAL,SMV
SMV Emblem Caution
1шт.
48
86547782
REFLECTOR,YELLOW
Yellow Retro Reflective
2шт.
49
86624775
WARNING DECAL
Set Machine To Clear Obstructions, English
1шт.
50
86624774
DANGER DECAL
Header May Fall Rapidly - English
2шт.
50
86625174
DANGER DECAL
DANGER, French
2шт.
50
86625175
DANGER DECAL
DANGER, Spanish
2шт.
51
86547783
REFLECTOR,Tape, Red Orange
Tape, Red/Orange Fluorescent
1шт.
52
787219
SLEEVE
2шт.
