Запчасти Case IH DC102 (08.02) - SHIELDING, LH (08) - SHEET METAL

1

86639656

COVER

1шт.

2

88682

CARRIAGE BOLT,Short Nk, 3/8"-16 x 1", Gr 5

1шт.

3

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

4шт.

4

510362

SPRING

DC102F

1шт.

5

86503933

SKIRT

Rubber, Left Hand, Includes: Ref. 6 - 11

1шт.

6

9604628

STRAP

Back-Up

1шт.

7

9604627

STRAP

1шт.

8

9604626

RING

D

1шт.

9

9707580

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd

5шт.

10

87361

WASHER,0.28" ID x 0.62" OD x 0.07" Thk

6шт.

11

280129

NUT,1/4"-20

7шт.

12

86627188

PLATE

Includes: Decal, 86604890

1шт.

13

88146

BOLT,Hex, 1/4" - 20 x 1", Gr 5

DC102F

4шт.

14

80577826

WASHER,8.7mm ID x 34.93mm OD x 1.94mm Thk

SAE, 5/16"

20шт.

15

145458

SERRATED NUT,5/16"-18 GR 5 ZND

1шт.

16

86639658

SHIELD

Left Hand

1шт.

17

216328

BUMPER

1шт.

18

87731421

DEFLECTOR

DC102F

1шт.

19

80701

WASHER,0.31" ID x 0.73" OD x 0.07" Thk

1шт.

20

9626558

FLANGE NUT,Flg, 1/4"-20

1шт.

21

86504855

CURTAIN

1шт.

22

87369972

FLAP

Rubber; See Also: Ref. 55

1шт.

23

86000448

LATCH

Rubber

2шт.

24

87545512

SPLASH SHIELD

1шт.

25

86627067

SHEET ASSY.

Left Hand

1шт.

26

280486

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5, Full Thd

1шт.

27

86513238

LOCK WASHER,.515” ID x 1.070” OD x .120” TK

Belleville, 1/2"

1шт.

28

86521607

FLANGE NUT,Flg, 1/2"-13, G5

1шт.

29

9628510

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

3шт.

30

80702

WASHER,0.44" ID x 1" OD x 0.08" Thk

2шт.

31

86639637

SHIELD

1шт.

32

86639634

SPRING

1шт.

33

86639646

SUPPORT

DC102

1шт.

33

86543258

SUPPORT

DC102F

1шт.

34

214539

WASHER,34.9mm ID x 50.8mm OD x 0.51mm Thk

1шт.

35

9800957

WASHER,35.81mm ID x 50.8mm OD x 1.52mm Thk

1шт.

36

87545529

SPLASH SHIELD

Cover, DC102

1шт.

Includes decals.

1шт.

37

86505993

BOLT,Hex, 1/2" - 13 x 4", Gr 5

2шт.

38

80700

WASHER,0.56" ID x 1.38" OD x 0.11" Thk

2шт.

39

86521610

FLANGE NUT,Flg, 1/2"-13

1шт.

40

86521614

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

DC102

1шт.

40

87868

CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5, Full Thd

DC102F

2шт.

41

86639654

DEFLECTOR

Left Hand, DC102

1шт.

41

86543475

DEFLECTOR

Left Hand, DC102F

1шт.

42

87399

COTTER PIN,1/2 x 3 Bolt

1шт.

43

86627071

BRACKET

Flat

1шт.

44

280430

CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5, Full Thd

6шт.

45

271288

BOLT,Hex Serr, 5/16" - 18 x 5/8", 5SPL, Full Thd

7шт.

46

86521606

FLANGE NUT,Hex, 3/8" - 16, Gr 5

13шт.

47

87034707

SHIELD

DC102

1шт.

48

86521605

FLANGE NUT,5/16"-18, Cl 5

1шт.

49

86639635

ANGLE

1шт.

50

280428

CARRIAGE BOLT,Short Nk, 5/16" - 18 x 1", Gr 5

3шт.

51

280327

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd

29шт.

52

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

4шт.

53

86543070

ANGLE

DC102F

1шт.
