(9-02) - TONGUE DECALS AND LOCATION DIAGRAM, SWIVEL

Запчасти Case IH 8312 (9-02) - TONGUE DECALS AND LOCATION DIAGRAM, SWIVEL (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH 8312 - (9-02) - TONGUE DECALS AND LOCATION DIAGRAM, SWIVEL (90) - PLATFORM, CAB, BODYWORK AND DECALS
6
5
2
1
3
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

700714229

DECAL

- warning

1шт.

2

700706863

DECAL

- warning

1шт.

3

192848A2

DECAL

- Case IH

2шт.

4

700714268

DECAL

- combo, left

1шт.

5

700714269

DECAL

- combo, right

1шт.

6

779199

DECAL

2шт.

Выбрано товаров: 6
