Запчасти Case IH 8312 (0A) - SUGGESTED STOCKING GUIDE, QUANTITY PER MACHINE 8312 (05) - SERVICE & MAINTENANCE

470077R91

BEARING ASSY,1.025" ID x 1.5325" OD x 4.309"

U-JOINT CROSS KIT

2шт.

054072

PULLEY

BELT TIGHTENER PULLEY

2шт.

6189971

SPRING

BELT TIGHTENER BOX SPRING

2шт.

700127058

SHOE

SKID-SHOE (standard)

8шт.

700127071

MOUNTING PARTS

KNIFE MOUNTING

16шт.

700127072

SHIELD

KNIFE BOLT SHIELD

16шт.

700127073

NUT

KNIFE RETAINING NUT

16шт.

700127414

OPEN END WRENCH

WRENCH (service tool)

1шт.

700128266

OPEN END WRENCH

WRENCH (service tool)

1шт.

700701079

LUBRICANT

GEAR BOX LUBRICATION

2шт.

700710242

KIT

MASTER CYLINDER SEAL KIT

1шт.

700711843

FLEXIBLE JOINT

HAY CONDITIONER U-JOINT CROSS KIT

2шт.

700711852

V-BELT,4292.6 mm L, 2 Ribs

2шт.

700711964

BOLT,Hex, 7/16" - 14 x , Gr 8

KNIFE RETAINING BOLT

16шт.

700712362

SEAL

GEAR BOX SHAFT SEAL

2шт.

700712367

GASKET

MAIN DRIVE GEAR GASKET

2шт.

700712389

OIL SEAL

GEAR BOX SEAL

1шт.

700712392

OIL SEAL

GEAR BOX SEAL

1шт.

700712412

SHIM

IDLER BEARING SHIM

28шт.

700712418

SHIM

IDLER BEARING SHIM

14шт.

700712419

THRUST BEARING,40mm ID x 80mm OD x 18mm W

IDLER GEAR BEARING

14шт.

700712544

JOURNAL

U-JOINT CROSS KIT

2шт.

700712569

DISC

FRICTION DISC

4шт.

700712574

YOKE

U-JOINT CROSS KIT

2шт.

700712633

PACKAGE, REPAIR

OVERRUNNING CLUTCH REPAIR KIT

1шт.

700712888

KNIFE

- clockwise

8шт.

700712889

KNIFE

- counter clockwise

8шт.

700714310

BALL BEARING,34.976 mm ID x 72.043 mm OD x 33 mm

SPINDLE BEARING

8шт.

7038649

SEAL KIT

SWING CYLINDER SEAL KIT

1шт.

757443

U-JOINT SPIDER

U-JOINT CROSS KIT

3шт.

H673838

SEAL

SLAVE CYLINDER SEAL KIT

1шт.

700713303

SHOE

HIGH CLEARANCE SKID, 8315 MOWER COND.

4шт.

700130189

CHANNEL

HIGH CLEARANCE SKID SHOES, 8315 MOWER COND.

4шт.

707042

BOLT,#3, 3/8" - 16 x 1", Gr 5

HIGH CLEARANCE SKID SHOES, 8315 MOWER COND.

8шт.

232-5316

FLANGE NUT,Flg, 3/8"-16

HIGH CLEARANCE SKID SHOES, 8315 MOWER COND.

8шт.
