Запчасти Case IH A8800 (60.350.AB[07]) - LIFT ARM, CROP DIVIDER - MY2016 (60) - PRODUCT FEEDING

1

47609393

SUPPORT

2шт.

2

86625255

WASHER,13.3mm ID x 24.5mm OD x 3mm Thk

16шт.

3

412123

LOCK WASHER,13.1mm ID x 21.1mm OD x 2.55mm Thk

8шт.

4

300389

BOLT,M12 x 1.75 x 35mm, Cl 8.8

8шт.

5

47932844

HYDRAULIC CYLINDER

Wirh Sensor, Incl 17

2шт.

5

48071182

HYDRAULIC CYLINDER

MY 2017, Incl 16

2шт.

6

47931674

SUPPORT

LH

1шт.

7

86977789

BOLT,Hex, M6 x 1.0 x 35mm, Cl 8.8

10шт.

8

86978777

CLAMP,17.5mm, Coat, 7.1mm Bolt Hole, P Type

2шт.

9

408517

PLATE

2шт.

10

408516

RETAINER

2шт.

11

47478144

OIL SCRAPER RING +0.

8шт.

12

86588450

WASHER,6.6mm ID x 12mm OD x 1.6mm Thk

18шт.

13

47877726

PLATE

2шт.

13

70928189

WASHER,1.06" ID x 1.75" OD x 0.09" Thk

MY 2017

2шт.

14

86508568

BOLT,Hex, M6 x 1 x 16mm, Cl 8.8

14шт.

15

86517328

LOCK WASHER,6.1mm ID x 11.8mm OD x 1.7mm Thk

14шт.

16

48075222

SEAL KIT

1шт.

17

47892085

SEAL KIT

1шт.
