Запчасти Case IH 7700 (A10[01]) - FULL TANK Mainframe & Functioning Components

1

87237322

CHASSIS

FRAME (LH) (Up to and including Serial # 9095)

1шт.

1

87256125

ASSEMBLY

FRAME (LH) (Serial # 9096 and onwards)

1шт.

1

87237323

CHASSIS

FRAME (RH) (Up to and including Serial # 9095)

1шт.

1

87256126

ASSEMBLY

FRAME (RH) (Serial # 9096 and onwards)

1шт.

2

87230477

AXLE DIFFERENTIAL

BEAM cross

1шт.

2

87234537

CHASSIS

BEAM cross [22"]

1шт.

4

87217925

GUARD

COVER [LH]

1шт.

4

87217926

GUARD

COVER [RH]

1шт.

5

87110500

SPROCKET ASSY.

2шт.

5

87223451

SPROCKET ASSY.

RING

2шт.

5

87110600

PLATE

centre

2шт.

5

00136030

BOLT

20шт.

5

00136031

NUT

20шт.

6

00139539

TRACK CHAIN

[48 Link]

2шт.

6

87252477

TRACK CHAIN

[S.A.L.T.]

2шт.

7

87219788

TRACK PLATE

GROUSER [18"] [bent]

94шт.

7

87243343

ANGLE

GROUSER [18"] [bent] [low profile]

94шт.

7

87220831

TRACK PLATE

GROUSER [18"] [bent master]

2шт.

7

87243344

ANGLE

GROUSER [18"] [bent master] [low profile]

2шт.

7

87222832

TRACK PLATE

GROUSER [20"] [bent]

94шт.

7

87226416

TRACK PLATE

GROUSER [20"] [bent master]

2шт.

7

87239104

PLATE

GROUSER [22"] [bent]

94шт.

7

87239105

ANGLE

GROUSER [22"] [bent master]

2шт.

8

00131447

SUPPORTING ARM

4шт.

8

00607865

BOLT

2шт.

9

00135809

BOLT

2шт.

10

87102000

PLATE

SEAL

2шт.

11

00100074

O-RING

2шт.

12

00146531

BEARING

2шт.

13

87238445

COVER ASSY

(Up to and including Serial #9095)

2шт.

13

87256137

COVER ASSY

(Serial # 9096 and onwards)

2шт.

14

87229548

RETAINING PLATE

4шт.

15

87226275

WEAR STRIP

4шт.

15

FD108050

SCREW,Flat Hd, Csk, M8 x 1.25 x 50mm

12шт.

15

NC108000

NUT

12шт.

17

00180908

TRACK PLATE

GROUSER [18"] [straight]

94шт.

17

00180909

TRACK PLATE

GROUSER [18"] [straight master]

2шт.

17

00135967

ASSEMBLY

GROUSER [20"] [straight]

94шт.

17

00139540

TRACK PLATE

GROUSER [20"] [straight master]

2шт.

17

00180702

PLATE

GROUSER [22"] [straight]

94шт.

17

00180703

TRACK PLATE

GROUSER [22"] [straight master]

2шт.

18

00146556

BEARING

2шт.

19

87254514

BEARING LOCK NUT

2шт.

20

87242108

COVER

2шт.

20

00601499

BOLT

6шт.

21

ROLLER track idler (Refer Figure A10.04)

1шт.

22

00601535

BOLT

BOLT

4шт.

23

CI042000

CIRCLIP

2шт.

24

00141584

BEARING

2шт.

25

00131438

BOLT

384шт.

26

00131437

NUT

384шт.

27

87245816

LOCKING PLATE

locking

2шт.

28

FC106025

SCREW,M6 x 25mm

2шт.
