Запчасти Case IH 7700 (B06[01]) - HYDRAULIC SUCTION LINES Hydraulic Components & Circuits

1

87240492

TUBE,50.80 mm OD x 260 mm L

TUBE

2шт.

2

86314466

HYD CONNECTOR,50.80 mm OD x 90 mm L

Tube

2шт.

3

441987A1

TUBE

1шт.

4

446616A1

CLAMP

12шт.

5

82204300

HOSE,50.8mm ID x 102mm L

4шт.

6

87240531

HYDRAULIC VALVE

Ball

2шт.

7

00606627

PIN

Lynch

2шт.

8

87240807

CHAIN,Assembly, Incl Lynch Pin

CHAIN

2шт.

9

441986A1

TUBE

1шт.

10

83123000

HOSE,2.00" ID x 4.63"

2шт.
