Запчасти Case IH PU3000 (09) - EQUIPOTENTIAL BONDING (58) - ATTACHMENTS/HEADERS

1

06701187

TENSION SPRING

8.5 x 46.5 x 534 PU3FO

1шт.

2

20335616

END FITTING

GG20 5307M37/1 RZ

1шт.

3

20335624

END FITTING

GG20 5307M38 RZ

1шт.

11

060512683

SCREW

hex, M12 x 140 DIN933 8.8

1шт.

12

829-1412

NUT,M12, Cl 10.9

1шт.

13

07640453

BOLT

BOLT, B12H11 x 40 x 35 DIN1444 ST

1шт.

14

06402394

PIN, SPLIT (COTTER)

PIN, COTTER 3.2 x 22 DIN94 ST

1шт.

15

07640035

LARGE PIN

PIN, LARGE BOLT, B20H11 x 75 x 68 DIN1444 ST

1шт.

16

06402730

PIN, SPLIT (COTTER)

PIN, COTTER 5 x 32 DIN94 ST

1шт.

21

36258162

LEVER

SWIVEL

1шт.
