Запчасти Case IH 2016 (60.220.14) - DRAPER AND GEAR BOX DRIVE, RAKE-UP (60) - PRODUCT FEEDING
№
Артикул
Название
Примечание
Количество
1
87675660
FRAME ASSY
Main, Inc. Decals, 12 Ft
1шт.
1
87675661
FRAME ASSY
Main, Inc. Decals, 14 Ft
1шт.
1
87675662
FRAME ASSY
Main, Inc. Decals, 16 Ft
1шт.
2
377387A1
BOLT
1/4" x 1/2", 6 Per Belt section
1шт.
3
374098A1
BELT
12 Ft, Rear Draper, Bolt Together
7шт.
3
87635819
BELT
12 Ft, Full Width, Grass Seed Special
1шт.
3
374098A1
BELT
14 Ft, Rear Draper, Bolt Together
8шт.
3
374098A1
BELT
16 Ft, Rear Draper, Bolt Together
9шт.
4
87462693
ROLLER,3820.5mm L
12 Ft, Rear, Rear Frame, Standard
1шт.
4
87494141
ROLLER
12 Ft, , Rear, Rear Frame,Grass Seed Special
1шт.
4
87462694
ROLLER,4302.5mm L
14 Ft, Rear, Rear Frame, Standard
1шт.
4
87462695
ROLLER
16 Ft, Rear, Rear Frame, Standard
1шт.
5
113-83
BOLT,Hex, 1/4" - 20 x 1-1/2", Gr 5, Full Thd
2шт.
6
87372130
BRACKET
Carrier, Adjustable Tab, Right Hand
1шт.
6
87372133
BRACKET
Carrier, Left Hand
1шт.
8
413-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5
12шт.
10
373909A1
PULLEY
Draper
1шт.
11
87616
SET SCREW,3/8" - 16 x 3/4"
1шт.
11
485-13816
SET SCREW,Sq Hd, 3/8"-16 x 1"
1шт.
12
NSS
NOT SOLD SEPARAT
HOUSING, Bearing
4шт.
13
156011C92
BALL BEARING
62mm OD
4шт.
14
NSS
NOT SOLD SEPARAT
COLLAR, Locking
4шт.
15
373987A1
BEARING ASSY
4шт.
16
Q26
KEY,1/4" Sq x 1 1/4", Par
2шт.
17
87451996
COUPLING,25.43mm ID x 63.5mm OD x 73mm L
Motor, 4 Bolt Holes
1шт.
18
492-11025
LOCK WASHER,1/4"
4шт.
19
87535228
BOLT
1/4" x 2-1/2"
2шт.
20
413-824
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
4шт.
22
87532623
CONE WASHER
12 mm
4шт.
23
231-4148
NUT,1/2"-13, GB
2шт.
24
373905A1
ARM
Belt Tightener
1шт.
25
87372631
BUSHING
Idler Arm
1шт.
26
374134A1
TIGHTENER
Spring
1шт.
27
413-848
BOLT,Hex, 1/2" - 13 x 3", Gr 5
1шт.
28
413-840
BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5
1шт.
29
87635814
PULLEY,102mm OD
Tightener
1шт.
30
495-81287
WASHER,13.49mm ID x 31.75mm OD x 3.4mm Thk
2шт.
31
413-640
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
1шт.
32
495-21044
WASHER,3/8"
1шт.
33
425-106
NUT,3/8"-16, Cl 5
1шт.
34
87616
SET SCREW,3/8" - 16 x 3/4"
2шт.
35
373912A1
PULLEY
1шт.
36
374100A1
V-BELT
1шт.
37
373880A1
GEARBOX ASSY
1шт.
37
373880A1R
REMAN-GEARBOX
Remanufactured Gearbox, N.A. Only
1шт.
37
373880A1C
CORE-GEARBOX
Return Number, Gearbox, N.A. Only
1шт.
38
373867A1
PLATE
Scroll, Right Hand Drive
1шт.
39
373990A1
ROTOR ASSY.
Drive End
1шт.
40
374632A1
WASHER
2" x 17/32" x 3/16"
1шт.
41
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
1шт.
42
373979A1
BOLT
1/2" x 1-1/2"
1шт.
43
87462696
ROLLER
Front, Rear Frame, 12 Ft, Standard
1шт.
43
87462698
ROLLER
Front, Rear Frame, 12 Ft, Grass Seed Special
1шт.
43
87462697
ROLLER
Front, Rear Frame, 14 Ft
1шт.
43
87462698
ROLLER
Front, Rear Frame, 16 Ft
1шт.
44
373946A1
PROTECTOR
Edge, 1 Per Belt
1шт.
45
9626558
FLANGE NUT,Flg, 1/4"-20
6 Per Belt
1шт.
46
413-620
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
4шт.
47
485-15048
SET SCREW,Sq Hd, 1/2"-13 x 3"
2шт.
48
374148A1
MOTOR, HYDRAULIC
74cc
1шт.
50
87642417
ARM
Torque, Hydraulic Motor
1шт.
51
413-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
4шт.
58
448681A1
BUSHING
Stamped 0
2шт.
58
448681A1
BUSHING
Stamped 50
3шт.
58
448681A1
BUSHING
Stamped 100
4шт.
58
448681A1
BUSHING
Stamped 150
5шт.
58
448681A1
BUSHING
Stamped 200
6шт.
59
440385A1
BUSHING
Locking
1шт.
60
495-11053
WASHER,1/2", SAE
1шт.
61
87372657
BUSHING
Flanged, Carrier Bracket
2шт.
62
87635817
PLUG
1-1/4"
1шт.
63
374138A1
BUSHING
1-1/4"
1шт.
64
374139A1
HUB
1шт.
65
389396A1
KEY
3/16" x 1/4" x 1-1/4"
1шт.
66
9707580
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
2шт.
67
322357
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
2шт.
68
87494153
DECAL
Draper Tension
1шт.
69
485-13816
SET SCREW,Sq Hd, 3/8"-16 x 1"
1шт.
70
376892A1
SEAL KIT
Orbit Motor Seal
1шт.
Выбрано товаров: 81
