Запчасти Case IH 525 (02-012) - CRANK ASSEMBLY (58) - ATTACHMENTS/HEADERS

1

20154R1

DOWEL,5/16" x 7/8"

PIN 5/16 x 7/8

1шт.

Part of Ref. 2, part number 700150974

1шт.

2

700150974

HOUSING

ASSEMBLY (Includes: Ref. 1 and 7)

1шт.

3

298194R91

ROLLER BEARING,44.45mm ID x 29.37mm W

1шт.

4

8044083

SEAL

external

1шт.

5

700110739

CRANK

ASSEMBLY (Includes: Ref. 6)

1шт.

6

83-616

SET SCREW,Hex Soc, 3/8"-16 x 1"

cup point hex socket, 3/8-16 x 1

1шт.

Part of Ref. 5, part number 700110739

1шт.

7

170254R1

BEARING, CUP

2шт.

Part of Ref. 2, part number 700150974

1шт.

8

219-90

LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF

ZERK, 1/4-28 x 45°

1шт.

9

912735R91

ROLLER BEARING,1.6255" ID x 1.1563"

CONE

1шт.

10

700110743

NUT

clamp

1шт.

11

61-33120

HEX SOC SCREW,5/16"-18 x 1 1/4"

SCREW hex socket head cap, 5/16-18 x 1-1/4 SPL

1шт.

12

700705444

DUST CAP

grease

1шт.
