Запчасти Case IH 325 (9-14) - STUB GUARD KIT (15 FOOT) (88) - ACCESSORIES

700151016

KIT

stub guard complete

1шт.

1

433-724

CARRIAGE BOLT,Sq Nk, 7/16" - 14 x 1 1/2", Gr 5

7/16-14 x 1-1/2 RHSNB

4шт.

2

425-107

NUT,7/16"-14, G5

60шт.

3

433-736

CARRIAGE BOLT,Sq Nk, 7/16" - 14 x 2 1/4", Gr 5

7/16-14 x 2-1/4 RHSNB

52шт.

4

49312

GUARD

double, bottom

29шт.

5

700106256

PLATE

upper

28шт.

6

1707215

BOLT

7/16-14 x 2-1/2 RHSNB

4шт.

7

6210652

GUARD

double

1шт.

8

700133232

GUARD

adjustable top, special

15шт.

9

700111956

PLATE

30шт.

10

700703319

SET SCREW,1/2" - 13 x 1/2"

1/2-13 xX 1/2 oval point socket set (with patch lock)

56шт.

11

700702736

GUARD

guard, adjustable

13шт.
