Запчасти Case IH 2060-17 (58.130.AQ) - SKID PLATE, 17FT (58) - ATTACHMENTS/HEADERS

1

47627711

Skid Shoe, Weld Assy

SIDE RAIL

2шт.

2

47627073

Skid Weld Assy, Center

PLATE

2шт.

3

120073

BOLT,Hex, M10 x 86.58mm, Cl 8.8

5шт.

4

378244

WASHER,10.5mm ID x 24mm OD x 2mm Thk

14шт.

5

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

38шт.

6

100016

NUT,M10 x 1.5, Cl 8

13шт.

7

43140

BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8

27шт.

8

47628362

Skid Shoe, Weld Assy, 17ft

SIDE RAIL

2шт.

9

47906017

LH Glide

PLATE

1шт.

10

86633356

CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8

2шт.

11

374892

CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8

1шт.
