Запчасти Case IH 2050 (18.87631825[01]) - DIA : VERTICAL KNIFE ELECTRICITY KIT - AXIAL-FLOW 7120/8120/9120 (18) - ACCESSORIES

87631825

DIA KIT, HARVESTER

1шт.

1

87632016

WIRE HARNESS

2шт.

2

87632017

WIRE HARNESS

1шт.

3

84444610

BRACKET

1шт.

4

86979554

CLAMP

1шт.

5

86979552

BRACKET

1шт.

6

86979559

WIRE HARNESS,700mm L

2шт.

7

86979558

WIRE HARNESS,240mm L

2шт.

8

86619908

RELAY,12V, 150A

2шт.

9

84078784

FUSE HOLDER

2шт.

10

84320251

SWITCH

1шт.

11

86590413

BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk

5шт.

12

86566989

CABLE TIE,208mm L

CABLE STRAP

25шт.

13

445394

RIVET,Pop, 3/16" x 1/2" OAL

5шт.

14

84320118

FUSE,40A, Midival

2шт.

15

86508568

BOLT,Hex, M6 x 1 x 16mm, Cl 8.8

7шт.

16

9706755

NUT,M6, Cl 8

7шт.

17

322357

BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk

7шт.

18

86508812

NUT,M3, Cl 8

4шт.

19

86511816

SCREW,Pan, M3 x 0.5 x 16mm, Cl 4.8

4шт.

20

86509827

LOCK WASHER,M3

8шт.

21

9861378

CONTACT HOUSING

1шт.
