1
277402A1
CYLINDER,Double Acting, 18.97mm Rod, 330.2mm Stroke
pickup reel
2шт.
See figure 08-07
1шт.
2
76344
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
4шт.
3
9617873
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
4шт.
4
1277506C1
HYDRAULIC HOSE,6.35mm ID x 1195mm L
Pick-up Reel
1шт.
5
183825C1
CLAMP
3/8" tubes
6шт.
7
9626558
FLANGE NUT,Flg, 1/4"-20
6шт.
8
86629586
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 Fem Sw
6шт.
9
141425A2
HOSE,0.25" ID x 57.00", SAE 100R1
1/4" x 57"
1шт.
10
812382C1
HYDRAULIC HOSE
1/4" x 50" fl
1шт.
10
147876C1
HYDRAULIC HOSE
1/4" x 45" fl, 3/8" fjic x 3/8" fjic
1шт.
13
147875C1
HYDRAULIC HOSE,6.40 mm ID x 890.00 mm, SAE 100R1
1шт.
15
1316598C1
TUBE,0.375" OD, 1613 mm Length
reel lift
1шт.
22.5 and 25.0 foot
1шт.
15
1338421C1
TUBE,0.375" OD, 3080 mm Length
reel lift
1шт.
30.0 foot
1шт.
16
1338420C1
HYDRAULIC HOSE,0.375" OD, 3080 mm Length
reel lift
1шт.
22.5 and 25.0 foot
1шт.
16
1338420C1
HYDRAULIC HOSE,0.375" OD, 3080 mm Length
reel lift
1шт.
30.0 foot
1шт.
17
1316602C2
TUBE,0.375" OD, 2229 mm Length
fore and aft
1шт.
22.5 foot
1шт.
17
138338A1
TUBE,0.375" OD, 2609 mm Length
fore and aft
1шт.
25.0 foot
1шт.
17
1338420C1
HYDRAULIC HOSE,0.375" OD, 3080 mm Length
reel lift
1шт.
30.0 foot, Longer Tube
1шт.
17a
1338414C1
TUBE,0.375" OD, 275 mm Length
reel lift
1шт.
15.0 foot
1шт.
18
1316597C1
TUBE,0.375" OD, 1413 mm Length
reel lift
1шт.
22.5 foot
1шт.
18
1316601C1
TUBE,0.375" OD, 1794 mm Length
reel lift
1шт.
25.0 foot
1шт.
18
1316604C1
TUBE,0.375" OD, 2556 mm Length
3/8" x 100"
1шт.
30.0 foot
1шт.
19
1316603C1
TUBE,0.375" OD, 2655 mm Length
reel lift
2шт.
22.5 foot
1шт.
19
1316605C1
HYD TUBE,0.375" OD, 3035 mm Length
3/8" x 119 1/2"
2шт.
25.0 foot
1шт.
19
1338420C1
HYDRAULIC HOSE,0.375" OD, 3080 mm Length
reel lift
2шт.
30.0 foot
1шт.
20
86513087
FITTING,Blkhd, 9/16"-18, 37 Degree x 9/16"-18, 37 Degree
1шт.
21
525646
HYD CONNECTOR,7/8" - 14 ORB x 9/16" - 18 JIC
2шт.
23
86525
LOCK NUT,Blkhd, 9/16"-18
1шт.
25
280317
BOLT,Hex, 1/4" - 20 x 3", Gr 5
6шт.
26
1326573C1
SPACER
45 mm long
6шт.
27
435437A1
CABLE TIE,3/16" x 7 1/4"
CABLE STRAP
2шт.
28
1954133C1
PLUG
plug assembly
1шт.
29
1282338C91
COUPLING, QUICK, FEM
7/8 NF, Self-Sealing
1шт.
30
167269
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
2шт.
33
1316779C2
SUPPORT
1шт.
34
87034817
SELF-TAP SCREW,HWH, 5/16" - 18 x 3/4"
2шт.
35
1321398C3
CLAMP
quick disconnect
1шт.
36
88542
BOLT,Hex, 1/4"-20 x 1/2", Gr 5
2шт.
37
1254527C2
HYDRAULIC HOSE
1/4" x 37" fl
1шт.
38
1541792C1
WASHER
red, special
1шт.
39
1272399C2
QUICK MALE COUPLING
self sealing, 7/8" NF
1шт.
41
523282
SERRATED NUT,Flg, USR, 1/4"-20
2шт.
45
485093C1
CLAMP,13/16" Insul, 13/32" Bolt
2шт.
46
80701
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
2шт.
47
87845
BOLT,Hex, 1/4" - 20 x 2 1/2", Gr 5
2шт.
48
9626558
FLANGE NUT,Flg, 1/4"-20
2шт.
50
87502800
BRACKET
cylinder mount RH, Start Serial: CBJ023001
1шт.
51
88043
BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5
2шт.
52
86992215
LOCK NUT,1/2"-13, GC
4шт.
53
87339
BOLT,Hex, 1/2" - 13 x 3", Gr 5
2шт.
54
87503707
BRACKET
cylinder mount LH, Start Serial: CBJ023001
1шт.
56
439-5628
HEADED PIN,3/8" x 1 3/4"
2шт.
57
86624081
HEADED PIN,9.53mm OD x 57.15mm L
2шт.
58
80756
COTTER PIN,1/8" x 3/4"
4шт.
59
251635A1
CAP
fitting aluminum 3/8" with seal
5шт.
60
251637A1
CAP
fitting aluminum 5/8" with seal
1шт.
