Запчасти Case IH 1010 (09D-14) - DECALS - ENGLISH LANGUAGE (09) - CHASSIS/ATTACHMENTS

14

296796A1

DECAL

auger lift bracket

2шт.

15

1284374C1

REFLECTOR,Reflector Red

red

2шт.

15

1284365C2

REFLECTOR

amber 1.97" x 4.3"

2шт.

19

1326528C1

DECAL

Danger, shield missing, do not operate

2шт.

20

1326752C1

DECAL

lubrication instruction, Start Serial: JJC0304189

2шт.

21

433531A1

DECAL

PTO driveline lubrication, Serial Range: -JJC0304189

2шт.

21

433531A2

DECAL

PTO driveline lubrication, Start Serial: JJC0304190

2шт.

24

1326618C1

DECAL

drive identification

1шт.

25

1326619C1

DECAL

fore/aft detent

1шт.

26

311863A1

REFLECTOR

Retroreflective Red

1шт.

27

311864A1

REFLECTOR

Retroreflective Amber 1.375" x 7.25"

1шт.

28

311865A1

REFLECTOR

fluorescent orange

1шт.
