Запчасти Case IH 1010 (09B-08) - KNIFE DRIVE (09) - CHASSIS/ATTACHMENTS

1

125959A1

PULLEY

drive, 500 rpm, 267 mm od

1шт.

1

125962A1

PULLEY

drive, 600 RPM, 12 17/32" od

1шт.

Use with 3 inch knife only

1шт.

1

126012A1

PULLEY

drive, 460 rpm, 245 mm OD

1шт.

Use with 1.5 inch knife only

1шт.

2

133587A1

FLANGE BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, W/ Scotch Grip

hex flange, self-locking, special, 3/8 NC x 3/4"

4шт.

3

125966A1

HUB

auger and knife drive

1шт.

4

9706716

BOLT,Hex, 1/2" - 13 x 2", Gr 5

2шт.

5

280431

NUT,1/2"-13, G5

2шт.

6

87450168

ROD

support, idler pulley, Start Serial: CBJ023001

1шт.

7

9706726

BOLT,Hex Flg, 3/8" - 16 x 1"

4шт.

8

247780

SERRATED NUT,Flg, USR, 3/8"-16

4шт.

9

132230A2

EYEBOLT

1/2 x 10 3/8"

1шт.

10

132231A1

SPACER

tightener belt

1шт.

11

1338456C1

IDLER

idler, 6" OD

1шт.

12

87339

BOLT,Hex, 1/2" - 13 x 3", Gr 5

1шт.

13

232-5318

FLANGE NUT,Flg, 1/2"-13

1шт.

14

REF

INSTRUCTION

Box Assy

1шт.

See Figure 09B-09A

1шт.

15

86508732

BOLT,5/8"-11 x 2.391" Cl 8

4шт.

16

426-1056

BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 8

1шт.

17

232-53110

FLANGE NUT,Flg, 5/8"-11

5шт.

18

126316A1

LARGE PLATE

PLATE, LARGE knife box support

1шт.

19

414077C1

BOLT,Hex, 5/8" - 18 x 1 3/4"

hex flange, special, 5/8 NC x 1 3/4"

2шт.

20

414089C1

FLANGE NUT,5/8" - 18

2шт.

21

247426A1

V-BELT,22.33 mm W x 2480.69 mm L

Knife drive, O.C., 500 rpm (Optional)

1шт.

Use with 125959A1, 126012A1

1шт.

21

319904A1

V-BELT,22.33 mm W x 2618.74 mm L

Knife drive, 600 rpm

1шт.

Use with 125962A1

1шт.

22

280431

NUT,1/2"-13, G5

2шт.

23

87364

WASHER,0.53" ID x 1.06" OD x 0.1" Thk

1шт.
