Артикул
Название
Примечание
Количество
1
87644249
HYDRAULIC CYLINDER,Double Acting, 28.7mm Rod, 238.51mm Stroke
1 1/2" x 9 3/8", Reel Lift Master, Start Serial: CBJ023001
1шт.
See Figure 08-09
1шт.
2
HYDRAULIC CYLINDER,25.32mm Rod, 238.25mm Stroke
1 x 9 3/8", Reel Lift Slave, Start Serial: CBJ023001
1шт.
See Figure 08-10
1шт.
128726A2R
REMAN-HYD CYLINDER
1010 P.I.N. CBJ023001 AND AFTER, Start Serial: CBJ023001 (11/04-)
1шт.
128726A2C
CORE-HYD CYLINDER
Return Number
1шт.
4
330346
45 ELBOW,45 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring
1шт.
7
87500971
ADAPTER,9/16" - 18 JIC x 9/16" - 18 JIC
, Start Serial: CBJ023001
1шт.
8
86525
LOCK NUT,Blkhd, 9/16"-18
1шт.
9
183821C1
CLAMP
tube, single, 3/8" OD tube
1шт.
10
183825C1
CLAMP
3/8" tubes
3шт.
12
280164
BOLT,Hex, 1/4" - 20 x 1 3/4", Gr 5
4шт.
13
1326572C1
SPACER
10 mm, long
4шт.
14
9626558
FLANGE NUT,Flg, 1/4"-20
4шт.
15
147875C1
HYDRAULIC HOSE,6.40 mm ID x 890.00 mm, SAE 100R1
3шт.
16
86637979
CLAMP,20.6mm, Coat, 10.3mm Bolt Hole, P Type
1шт.
17
485093C1
CLAMP,13/16" Insul, 13/32" Bolt
1шт.
18
9706726
BOLT,Hex Flg, 3/8" - 16 x 1"
2шт.
19
247780
SERRATED NUT,Flg, USR, 3/8"-16
2шт.
20
1338418C1
TUBE,0.375" OD, 2844 mm Length
reel lift
1шт.
15.0 and 17.5 foot
1шт.
20
1338421C1
TUBE,0.375" OD, 3080 mm Length
reel lift
1шт.
20.0 foot
1шт.
21
1316601C1
TUBE,0.375" OD, 1794 mm Length
reel lift
1шт.
15.0 foot
1шт.
21
1316604C1
TUBE,0.375" OD, 2556 mm Length
3/8" x 100"
1шт.
17.5 foot
1шт.
21
1338420C1
HYDRAULIC HOSE,0.375" OD, 3080 mm Length
reel lift
1шт.
20.0 foot
1шт.
23
1338419C1
TUBE,0.375" OD, 3027 mm Length
reel lift
1шт.
24
1338414C1
TUBE,0.375" OD, 275 mm Length
reel lift
1шт.
15.0 foot
1шт.
24
1338416C1
TUBE,0.375" OD, 652 mm Length
reel lift
1шт.
17.5 foot
1шт.
24
1316596C1
TUBE,0.375" OD, 1033 mm Length
reel lift
1шт.
20.0 foot
1шт.
25
1541804C1
WASHER
black, special
1шт.
26
525646
HYD CONNECTOR,7/8" - 14 ORB x 9/16" - 18 JIC
1шт.
29
251635A1
CAP
fitting aluminum 3/8" with seal
4шт.
Выбрано товаров: 45
