Запчасти Case IH 8830 (9-102) - CLUTCH CONTROL ELECTRICAL ASSEMBLY (58) - ATTACHMENTS/HEADERS

1

700709114

HARNESS

- wire

1шт.

2

700715685

RELAY

1шт.

3

121-3

SERRATED BOLT,Hex, 1/4" - 20 x 1/2", Gr 5

1шт.

4

231-5144

SERRATED NUT,Flg, USR, 1/4"-20

1шт.

5

700705661

WIRE HARNESS

WIRE - electrical

1шт.

6

700707061

WIRE

- electrical

1шт.

7

700706896

SWITCH

1шт.

8

700709111

WIRE HARNESS

HARNESS - wire

1шт.

9

8025637

SWITCH

1шт.

10

496-11041

WASHER,13/32" x 13/16" x .065", HDN

3/8 HARDENED PLAIN WASHER

1шт.

11

700118573

BRACKET

MOUNTING - switch

1шт.
