Запчасти Case IH 8820 (9-104) - VALVE ASSEMBLY, REEL DRIVE (58) - ATTACHMENTS/HEADERS

1

7046956

ELBOW

45 DEGREE ELBOW (Includes item 40)

1шт.

2

409-7612

BOLT,3/8"-16 x 1.09" OAL

3/8-16 X 3/4 HWHMS

4шт.

3

231-5146

FLANGE NUT,3/8"-16

4шт.

4

700708988

HYDRAULIC HOSE,19.05 mm ID x 550.00 mm, SAE 100R1

19.05 mm ID x 550.00 mm, SAE 100R1

2шт.

5

1661297

MOUNTING PARTS

SUPPORT

1шт.

6

113-12

BOLT,Hex, 1/4" - 20 x 2-1/2", Gr 5

1/4-20 X 2-1/2 C

2шт.

7

231-5144

SERRATED NUT,Flg, USR, 1/4"-20

2шт.

8

218-837

TEE,37 Degree, 1 1/16"-12 x 1 1/16"-12, Fem Sw Br

FITTING - tee

1шт.

9

218-5221

TEE,37 Degree, 1 1/16"-12 x 1 1/16"-12, Fem Sw Run

1шт.

10

218-785

REDUCER,37 Degree, 1 1/16"-12, Fem x 7/8"-14 Male

FITTING - adapter

1шт.

11

515-23254

CLAMP,1", Insul, 3/8" Bolt

Line 1", Insul, 3/8" Bolt

4шт.

12

256873

BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd

2шт.

13

700124478

SUPPORT

1шт.

14

434-616

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5

3/8-16 X 1 RHSNB

4шт.

15

496-11041

WASHER,13/32" x 13/16" x .065", HDN

3/8 HARDENED PLAIN WASHER

4шт.

16

425-106

NUT,3/8"-16, Cl 5

4шт.

17

700124480

ROD

WA

1шт.

18

H436396

COUPLING

- quick disconnect

2шт.

19

1-7141

FITTING

NIPPLE - quick disconnect

2шт.

20

700711902

HYDRAULIC HOSE,12.70 mm ID x 1550.00 mm, SAE 100R2

12.70 mm ID x 1550.00 mm, SAE 100R2

1шт.

21

700711901

HYDRAULIC HOSE,12.70 mm ID x 1425.00 mm, SAE 100R2

12.70 mm ID x 1425.00 mm, SAE 100R2

1шт.

22

7027360

GROMMET

1шт.

23

700707494

ADAPTER

1шт.

24

700124486

COVER

WA

1шт.

25

700712110

DECAL

- notice

1шт.

26

700712111

DECAL

- notice

1шт.

27

218-5231

ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw

1шт.

28

218-5065

HYD CONNECTOR,1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB

CONNECTOR, HYD., , Fitting - elbow 1 1/16"-12, 37º x 7/8"-14, O-Ring

2шт.

29

217-352

FITTING,90 Degree Elbow, 1" Hose Barb x 1-5/16" - 12 Male ORB

- elbow (Includes item 39)

1шт.

30

214-1420

HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm

CLAMP, HOSE, #20, 0.81/1.75 Type F Worm

2шт.

31

700712178

HYDRAULIC HOSE,12.70 mm ID x 3500.00 mm, SAE 100R2, SAE J517

12.70 mm ID x 3500.00 mm, SAE 100R2, SAE J517

1шт.

32

492-11038

LOCK WASHER,3/8"

2шт.

33

L18337

CABLE TIE,9.95"-12.1" lg

STRAP - tie, 15 inch, nylon

4шт.

34

51200289

FITTING

- adapter (Includes item 40)

1шт.

35

7796394

VALVE

- flow control

1шт.

36

700124477

MOUNTING PARTS

MOUNTING - valve

1шт.

37

700708577

HOSE,25.40 mm ID x 1800.00 mm, SAE 100R3, SAE J517

Hydraulic 25.40 mm ID x 1800.00 mm, SAE 100R3, SAE J517

1шт.

38

7746274

INSERT

FITTING - insert

1шт.

39

738476

O-RING

1шт.

40

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

10-1, 90 Duro, .755" ID x .097" Thk

4шт.
