1
87491414
CONVEYOR
Assy, RH 40FT
1шт.
2
87477203
ARM
Assy, Rear
1шт.
3
87478446
ARM
Assy, RH
1шт.
4
87701210
ROLLER,60.33mm OD x 996mm L
Assy, Idler
1шт.
5
84476056
ROLLER,66.3mm OD x 1051mm L
Assy, Drive
1шт.
6
87473099
ADJUSTER
Drive Roller
1шт.
7
47478705
ARM
RH
1шт.
8
87478432
ARM
Assy
1шт.
9
394631
WASHER,17mm ID x 34mm OD x 4mm Thk
4шт.
10
15980321
BOLT,Hex, M16 x 1.5 x 25mm, Cl 8.8, Full Thd
3шт.
11
120044
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
2шт.
12
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
2шт.
13
9706685
NUT,M12 x 1.75, Cl 8
2шт.
14
140017
WASHER,M10 x 20mm OD x 2mm Thk
5шт.
15
100016
NUT,M10 x 1.5, Cl 8
9шт.
16
87478448
STABILIZER
Assy, RH
1шт.
17
86633356
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
1шт.
18
86512446
CARRIAGE BOLT,M10 x 1.5 x 30mm, Cl 8.8
1шт.
19
87473100
ROD
Threaded
1шт.
20
140045
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
9шт.
21
87477205
BRACKET
Assy
1шт.
22
280251
COTTER PIN,3/32" OD x 1" OAL
1шт.
23
87478996
INDICATOR
Assy
1шт.
24
626698
SPACER
1шт.
25
43139
BOLT,M10 x 1.5 x 25mm, Cl 8.8
5шт.
26
87478451
SUPPORT
Assy
1шт.
27
87529126
WASHER,0.53" ID x 1.75" OD x 0.1" Thk
1шт.
28
140018
WASHER,13.5mm ID x 24mm OD x 2.5mm Thk
1шт.
29
9706687
BOLT,M12 x 1.75 x 30mm, Cl 8.8
2шт.
30
87305403
SPACER,13.51mm ID x 19.05mm OD x 17.5mm Thk
1шт.
31
323238
THIN NUT,Hex, M12, 1.75mm Pitch, Cl 05
1шт.
32
87491665
LEAF SPRING
Assy
1шт.
33
87491663
LEAF SPRING
Assy
1шт.
34
47422735
BELLCRANK
Assy, RH
1шт.
35
9814566
BOLT,Hex, M16 x 2 x 190mm, Cl 8.8, Full Thd
1шт.
36
87477200
NUT,Special
1шт.
37
87311354
SPACER,10.7mm ID x 17.1mm OD x 14.2mm L
1шт.
38
43140
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
1шт.
39
86625253
WASHER,11mm ID x 24mm OD x 2mm Thk
1шт.
40
100038
NUT,M12 x 1.75, Cl 8
1шт.
41
84487818
BELT
Assy, Belt
1шт.
42
80425
SET SCREW,Hex Soc, 3/8"-16 x 3/8"
1шт.
43
84393903
HYDRAULIC MOTOR,41CC
Also Order 44 - 46
1шт.
44
86579694
ELBOW,90 Degree, 1"-14 ORFS x M22 x 1.5 ORB
1шт.
45
86579680
HYD CONNECTOR,1"-14 ORFS x M22 x 1.5mm ORB
1шт.
46
9993143
HYD CONNECTOR,11/16" - 16 ORFS x 9/16" - 18 ORB
1шт.
47
47371025
SLAT
Kit
1шт.
