1
84390059
DIVIDER
Right Hand, Flex
1шт.
1
84521513
BRACKET
Right Hand, Rigid
1шт.
2
84218894
MOUNT
Right Hand
1шт.
3
84218956
SUPPORT
Right Hand
1шт.
4
140048
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
4шт.
5
354360
BOLT,Hex, M16 x 2 x 130mm, Cl 8.8
1шт.
6
84164504
SPACER,11mm ID x 25mm OD x 37mm L
Stepped
1шт.
7
394632
WASHER,21mm ID x 40mm OD x 4mm Thk
1шт.
8
84306405
LINKAGE
Right Hand
1шт.
9
84306495
LINKAGE
Right Hand
1шт.
10
86512447
CARRIAGE BOLT,Short Square Neck, M10 x 60mm, Class 8.8
1шт.
11
140045
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
3шт.
12
100016
NUT,M10 x 1.5, Cl 8
3шт.
13
84137057
SPACER,11mm ID x 25mm OD x 50.8mm L
Lower Pivot
1шт.
14
83931335
BOLT,Hex, M10 x 1.5 x 75mm, Cl 8.8
1шт.
15
86633356
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
1шт.
16
84173226
DIVIDER
Right Hand
1шт.
17
84229093
DIVIDER POINT
Point
1шт.
18
84147660
PLATE
1шт.
19
120062
BOLT,Hex, M8 x 70mm, Cl 8.8
2шт.
20
322358
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
9шт.
21
86629542
NUT,M8 x 1.25, Cl 8.8
2шт.
22
252687
WASHER,0.34" ID x 0.75" OD x 0.09" Thk
2шт.
23
87488952
DEFLECTOR
Crop
1шт.
24
120107
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8, Full Thd
2шт.
25
328754
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
4шт.
26
140046
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
7шт.
27
337475
NUT,M12, Cl 10
4шт.
28
84216625
BRACKET
1шт.
29
84137037
SPACER,17mm ID x 29.98mm OD x 93.15mm L
Lower Pivot
1шт.
30
86507486
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
2шт.
31
43158
BOLT,Hex, M12 x 80mm, Cl 8.8
2шт.
32
120104
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
3шт.
33
9706690
NUT,M8 x 1.25, Cl 8
2шт.
34
84556812
LINK
1шт.
35
120044
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
1шт.
36
412672
NUT,Hex, M12 x 1.75, Cl 10
2шт.
37
87033290
CARRIAGE BOLT,Sht Sq Nk, M12 x 55mm, Cl 8.8
1шт.
38
210022
BUSHING
2шт.
39
43167
BOLT,Hex, M16 x 30mm, Cl 8.8, Full Thd
2шт.
40
84229082
ROD
Extension
1шт.
41
369441A1
DECAL
White
1шт.
42
84229083
DIVIDER
Extension Assy, Incl 40 - 41, 17
1шт.
