Запчасти Case IH 684 (0020) - CHAIN DRIVE, OUTER (58) - ATTACHMENTS/HEADERS

8

800-2162

SNAP RING,M62, Int

x 2 DIN472 FST

4шт.

12

03652122

BEARING

grooved ball, 6209, DIN625

2шт.

14

233202N0

RING ASSY.

SHIM, 75 x 85 x 0.1

2шт.

15

06453291

CIRCLIP

RING snap, 85 x 3/FST, DIN472

2шт.

19

03222553

WASHER

13 x 40 x 6

2шт.

20

239389N0

WASHER

A12

2шт.

21

239049N0

SCREW

BOLT hex, M12 x 30, MK/8.8-A3C, ISO4017

2шт.

31

97022663

SHIM

30 x 42 x 0.5, DIN988, ST

2шт.

32

97022172

SHIM

30 x 42 x 1.0, DIN988, ST

2шт.

33

233203N0

RING ASSY.

SHIM, 75 x 85 x 0.3

2шт.

34

233204N0

RING ASSY.

SHIM, 75 x 85 x 0.5

2шт.
