Запчасти Case IH 430WN (F-15) - STALK ROLL CONTROL (58) - ATTACHMENTS/HEADERS

1

580187R91

SHAFT ASSY, stalk roll control

4шт.

2

586016R91

HOUSING ASSY, stalk roll cam LH

2шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

8шт.

NLS

NO LONGER SERVICED

7/16-14 hex

8шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

8шт.

3

80711

LUBE NIPPLE,65 Degree, 1/8" NPT x 7/8" lg

FITTING, 1/8-27 67-1/2 deg lub

4шт.

4

586017R91

HOUSING ASSY, stalk roll cam RH

2шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

8шт.

NLS

NO LONGER SERVICED

7/16-14 hex

8шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

8шт.

5

587511R1

ANCHOR, stalk roll support

6шт.

17296R1

LOCK NUT,3/4"-16

NUT, 3/4-16 ESNA lock

4шт.

103326

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

3шт.

Q216

WASHER

1-3/32 x 1-3/4 x 16 ga

32шт.

Q5099

WASHER

25/32 x 1-3/4 x 11 ga

4шт.

6

580184R1

BUSHING, stalk roll support anchor, 429WN serial no. 1908 and below, 430WN serial no. 1500 and below

4шт.

6

158783C1

BUSHING

stalk roll support anchor, 429WN serial no. 1909 and above, 430WN serial no. 1501 and above

4шт.

7

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg

4шт.

8

589692R91

HUB ASSY, stalk roll support RH

2шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

8шт.

NLS

NO LONGER SERVICED

7/16-14 hex

8шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

8шт.

9

589691R91

HUB ASSY, stalk roll support LH

2шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

8шт.

NLS

NO LONGER SERVICED

7/16-14 hex

8шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

8шт.

10

580180R1

CAM, stalk roll adjustment LH

2шт.

11

580181R1

CAM, stalk roll adjustment RH

2шт.

12

580184R1

BUSHING, stalk roll adjustment cam, 429WN serial no. 1908 and below, 430WN serial no. 1500 and below

4шт.

12

158783C1

BUSHING

stalk roll adjustment cam, 429WN serial no. 1909 and above, 430WN serial no. 1501 and above

4шт.

13

584453R1

PIN

3/8 x 1-5/16 chamfred str

4шт.

14

589702R1

ROD, stalk roll control

4шт.

432-1216

COTTER PIN,3/16" x 1"

Pin, Split (Cotter), 3/16" x 1"

4шт.

15

104039

ADJUSTABLE CLEVIS,1/2"-20 x 3"

CLEVIS, 1/2-20 x 3 light adj rod end

4шт.

103385

COTTER PIN,1/8" x 1"

PIN, SPLIT (COTTER), 1/8" x 1"

4шт.

114787

AXLE PIN

PIN, 1/2 x 1-27/64 rod end

4шт.

16

589709R91

HUB ASSY, stalk roll control cam

4шт.

577139R1

LOCK PIN,3/8" x 1 1/2", Slotted

Pin, 3/8" x 1 1/2", Slotted

4шт.

17

589700R91

CABLE, stalk roll control

1шт.

103026

NUT,3/8"-24, G5

2шт.

18

939060R91

PIPE ASSY, stalk roll control torsion, 30 inch row spacing

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

4шт.

86508749

CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5

BOLT, 3/8 x 1-1/8 sq-nk crg

4шт.

102635

NUT,3/8"-16, G5

8шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

8шт.

18

150278C91

PIPE ASSY, stalk roll control torsion, 36, 38 and 40 inch row spacing

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

2шт.

102635

NUT,3/8"-16, G5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

19

589356R1

BRACKET, stalk roll control cable

1шт.

15007R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G2

1шт.

88707

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/4", Gr 5, Full Thd

BOLT, CARRIAGE, Short NK, 1/2"-13 x 1 1/4", G5, Full Thd

1шт.

9635082

NUT,5/16" - 18, Gr 5

5/16-18 hex

1шт.

102637

NUT,1/2"-13, G5

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

20

33175A

O-BOLT, stalk roll control cable

2шт.

102635

NUT,3/8"-16, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

21

150531C1

BRACKET, stalk roll control

1шт.

17448R1

BOLT (SPREADER)

BOLT, 1/2 x 1-1/4 hex-hd mach

2шт.

102637

NUT,1/2"-13, G5

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

22

589704R1

SECTOR, stalk roll control

1шт.

179837

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

23

589705R1

BRACKET, stalk roll torque pipe

1шт.

179837

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

Q1597

WASHER

13/32 x 3/4 x 16 ga

2шт.

24

589706R91

PIPE ASSY, stalk roll torque, 430WN serial no. 1500 and below, 429WN serial no. 1908 and below

1шт.

17673R1

BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 2

3/8 x 3-1/2 hex-hd mach

1шт.

231-1446

NUT,3/8" - 16, Gr 5

NUT, LOCK, , Esna stop 3/8"-16, GB

1шт.

17069R1

LOCK PIN,5/16" x 1 3/4", Slotted

Pin, 5/16" x 1 3/4", Slotted

1шт.

Q1597

WASHER

13/32 x 3/4 x 16 ga

1шт.

Q3481

WASHER

1-1/32 x 1-1/2 x 16 ga

3шт.

24

161037C91

PIPE ASSY, stalk roll torque, 429WN serial no. 1909 and above, 430WN serial no. 1501 and above

1шт.

17673R1

BOLT,Hex, 3/8" - 16 x 3 1/2", Gr 2

3/8 x 3-1/2 hex-hd mach

1шт.

231-1446

NUT,3/8" - 16, Gr 5

NUT, LOCK, , Esna stop 3/8"-16, GB

1шт.

17098R1

LOCK PIN,3/8" x 1 3/4", Slotted

PIN, 3/8" x 1 3/4", Slotted

1шт.

Q1597

WASHER

13/32 x 3/4 x 16 ga

1шт.

Q3481

WASHER

1-1/32 x 1-1/2 x 16 ga

3шт.

25

C33464

SPRING, stalk roll control lever

1шт.

26

568043R1

GRIP, stalk roll control lever

1шт.

27

589707R1

PIPE, stalk roll control

1шт.

17069R1

LOCK PIN,5/16" x 1 3/4", Slotted

Pin, 5/16" x 1 3/4", Slotted

1шт.

28

104038

ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"

CLEVIS, 3/8-24 x 2-1/2 rod end stalk roll control cable

2шт.

103373

COTTER PIN,3/32" x 3/4"

Pin, Split (Cotter), 3/32" x 3/4"

2шт.

NLS

NO LONGER SERVICED

PIN, 3/8 x 1-3/32 rod end

2шт.

29

589792R1

SHIELD, stalk roll control torsion

2шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

6шт.

NLS

NO LONGER SERVICED

7/16-14 hex

6шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

6шт.

30

589788R91

1шт.

ARM ASSY, stalk roll control, 1 used 30 inch row spacing, 3 used 36, 38 and 40 inch row spacing, 429WN serial no. 1908 and below, 430WN serial no. 1500 and below, 2 used 36, 38 and 40 inch row, 429WN serial no. 1909 and above, 430WN serial no. 1501 and above

1шт.

576517R1

LOCK PIN,1/4" x 1 1/2", Slotted

Pin, 1/4" x 1 1/2", Slotted

1шт.

30

161034C91

ARM ASSY, stalk roll control, 429WN serial no. 1909 and above, 430WN serial no. 1501 and above

1шт.

577139R1

LOCK PIN,3/8" x 1 1/2", Slotted

Pin, 3/8" x 1 1/2", Slotted

1шт.

31

150282C1

ANGLE, stalk roll torsion pipe LH, 36, 38 and 40 inch row spacing

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

2шт.

102635

NUT,3/8"-16, G5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

32

150283C1

ANGLE, stalk roll torsion pipe RH

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

2шт.

102635

NUT,3/8"-16, G5

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.
