Запчасти Case IH 430WN (F-06) - AUGER, BEATER AND DRIVE (58) - ATTACHMENTS/HEADERS
№
Артикул
Название
Примечание
Количество
1
938994R91
AUGER ASSY, 30 inch row
1шт.
1
150245C91
AUGER ASSY, 36, 38 and 40 inch row spacing
1шт.
181427
BOLT,Hex, 1/2" - 20 x 1", Gr 5
SCREW, 1/2-20 x 1 hex-hd cap
1шт.
115551
LOCK WASHER,Int Tooth, 1/2"
WASHER, LOCK, Int Tooth, 1/2"
2шт.
NLS
NO LONGER SERVICED
LOCK, 1 1/4"
1шт.
21585D
WASHER
17/32 x 1-3/4 x 3/16
1шт.
2
632156R1
THRUST WASHER
auger shaft
8шт.
3
654283R1
THRUST WASHER
auger shaft RH
1шт.
4
632157R1
SPACER, auger shaft
1шт.
5
156011C91
BALL BEARING
BEARING ASSY, auger shaft LH relube ball
1шт.
5
617668R91
BALL BEARING
ASSY, auger shaft LH ball, not relube brg
1шт.
6
939460R91
FLANGE
W/65 DEG FITTING, brg, for relube brg
2шт.
6
571425R1
FLANGED BEARING
auger shaft brg, not relube brg
2шт.
14995R1
BOLT
3/8 x 3/4 sq-nk crg
6шт.
102635
NUT,3/8"-16, G5
6шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
6шт.
7
654967R1
SPROCKET, beater drive LH 8T
1шт.
8
935789R91
SPROCKET ASSY, auger driven 50T
1шт.
9
577147R1
KEY
5/16 x 1-3/16 sq parallel
2шт.
10
156011C91
BALL BEARING
BEARING ASSY, auger shaft RH relube ball
1шт.
10
617668R91
BALL BEARING
ASSY, auger shaft RH ball, not relube brg
1шт.
11
557995R11
COLLAR
W/SET SCREW, auger shaft RH
1шт.
115321
SET SCREW,Hex Skt, 5/16"-18 x 5/16"
SCREW, 5/16-18 x 5/16 hex-soc-hd cup-pt set
1шт.
12
586359R1
SPROCKET, beater drive RH 8T
1шт.
13
587016R1
KEY, 1/4 x 3/4 sq parallel
1шт.
14
634470R1
BAT
auger
2шт.
15
634471R1
STRAP, auger bat retainer
2шт.
86508749
CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5
BOLT, 3/8 x 1-1/4 sq-nk crg
8шт.
102635
NUT,3/8"-16, G5
8шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
8шт.
16
939020R92
END ASSY, auger trough LH
1шт.
14986R1
BOLT, 5/16 x 1/2 sq-nk crg
4шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
4шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
8шт.
17
939021R92
END ASSY, auger trough RH
1шт.
14986R1
BOLT, 5/16 x 1/2 sq-nk crg
4шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
4шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
8шт.
18
939005R11
TROUGH ASSY, auger LH, 30 inch row spacing
1шт.
18
150242C11
TROUGH ASSY, auger LH, 36, 38 and 40 inch rows
1шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
6шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
7шт.
120283
SCREW,Hex, 5/16" x 3/4", Gr 5
5/16-18 x 1 slt-truss-hd mach
1шт.
Q397
WASHER
11/32 x 3/4 x 16 ga
6шт.
19
939006R11
TROUGH ASSY, auger RH, 30 inch rows
1шт.
19
150243C11
TROUGH ASSY, auger RH, 36, 38 and 40 inch row spacing
1шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
6шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
7шт.
120283
SCREW,Hex, 5/16" x 3/4", Gr 5
5/16-18 x 1 slt-truss-hd mach
1шт.
Q397
WASHER
11/32 x 3/4 x 16 ga
6шт.
20
939017R1
ANGLE, auger trough front, 30 inch row spacing
3шт.
20
150232C1
ANGLE, auger trough front outer, 36 inch row spacing
2шт.
20
150233C1
ANGLE, auger trough front outer, 38 inch row spacing
2шт.
20
150234C1
ANGLE, auger trough front outer, 40 inch row spacing
2шт.
20
150235C1
ANGLE, auger trough front center, 36, 38 and 40 inch row spacing
1шт.
21
939015R1
SECTION, auger front center, 30 inch row spacing
1шт.
21
150244C1
SECTION, auger front center, 36, 38 and 40 inch row spacing
1шт.
14995R1
BOLT
3/8 x 3/4 sq-nk crg
1шт.
102635
NUT,3/8"-16, G5
1шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
1шт.
22
939007R1
ANGLE, auger door, 30 inch row spacing
2шт.
22
150241C1
ANGLE, auger door, 36, 38 and 40 inch row spacing
2шт.
14986R1
BOLT, 5/16 x 1/2 sq-nk crg
6шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
2шт.
15007R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G2
2шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
10шт.
523
939011R91
DOOR ASSY, auger LH, 30 inch row spacing
1шт.
23
150497C91
DOOR ASSY, auger LH, 36, 38 and 40 inch row spacing
1шт.
24
939012R91
DOOR ASSY, auger, 30 inch row spacing
1шт.
24
150498C91
DOOR ASSY, auger RH, 36, 38 and 40 inch row spacing
1шт.
25
939018R1
ROD, auger door hinge, 30 inch row spacing
1шт.
25
150240C2
ROD, auger door hinge, 36, 38 and 40 inch spacing
2шт.
26
151318C1
SHAFT, beater, 30 inch row spacing
2шт.
26
151323C1
SHAFT, beater, 36, 38 and 40 inch row spacing
2шт.
120731
WASHER,1 1/8"
1 1/8"
2шт.
27
472323R1
WASHER
beater shaft
18шт.
28
939083R1
SECTION, beater drum, 30 inch row spacing
6шт.
28
150258C1
SECTION, beater drum, 36, 38 and 40 inch row spacing
6шт.
181336
BOLT,Hex, 5/16" - 24 x 3/4", Gr 5
24шт.
Q397
WASHER
11/32 x 3/4 x 16 ga
24шт.
29
939084R1
BAT, beater drum, 30 inch row spacing
6шт.
29
150257C1
BAT, beater drum, 36, 38 and 40 inch row spacing
6шт.
151446C1
SERRATED SCREW,Flg Lock, Sl Truss Hd, 5/16" - 18 x 1 1/4"
5/16 x 1-1/4 slt-truss-hd whiz lock
1шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
1шт.
115548
LOCK WASHER,Int Tooth, 5/16"
WASHER, LOCK, Int Tooth, 5/16"
1шт.
30
939475R91
BEARING
ASSY, beater shaft drive end relube ball
3шт.
30
455965R91
BALL BEARING,1.0005" ID x 52 mm OD x 15 mm
ASSY, beater shaft ball, not relube brg
3шт.
31
557115R11
COLLAR
COLLAR, w/set screw, lkg
2шт.
115321
SET SCREW,Hex Skt, 5/16"-18 x 5/16"
SCREW, 5/16 x 5/16 hex-soc-hd cup-pt set
2шт.
32
939475R91
BEARING
ASSY, beater shaft relube ball
1шт.
32
455965R91
BALL BEARING,1.0005" ID x 52 mm OD x 15 mm
ASSY, beater shaft ball, not relube brg
1шт.
33
939460R91
FLANGE
ASSY, brg, for relube brg
4шт.
33
571424R1
FLANGE
beater shaft brg, not for relube brg
4шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
12шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
12шт.
34
151320C2
BRACKET, beater outer LH brg
1шт.
14995R1
BOLT
3/8 x 3/4 sq-nk crg
2шт.
102635
NUT,3/8"-16, G5
2шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
2шт.
35
151321C2
BRACKET, beater outer RH brg
1шт.
14995R1
BOLT
3/8 x 3/4 sq-nk crg
2шт.
102635
NUT,3/8"-16, G5
2шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
2шт.
36
151319C1
BRACKET, beater inner brg
2шт.
15010R1
CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2
BOLT, 1/2 x 1 sq-nk crg
4шт.
102637
NUT,1/2"-13, G5
4шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
4шт.
37
632194R1
BRACKET, beater chain tightener
2шт.
14995R1
BOLT
3/8 x 3/4 sq-nk crg
4шт.
102635
NUT,3/8"-16, G5
4шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
4шт.
38
583619R1
BLOCK
beater chain tightener
1шт.
38
583620R1
BLOCK
beater chain tightener
1шт.
15007R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G2
2шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
2шт.
39
151013C1
SPROCKET, beater driven 13T
2шт.
103387
COTTER PIN,1/8" x 1 1/2"
Pin, Split (Cotter), 1/8" x 1 1/2"
2шт.
575810R1
WASHER
21/32 x 1-1/2 x 11 ga
2шт.
40
577147R1
KEY
5/16 x 1-3/16 sq parallel
1шт.
41
CHAIN, beater drive roller, use 45 links from 10 ft roll marked 569089R91 and one connecting link 587372R91
2шт.
42
939085R1
SHIELD, beater, 30 inch row spacing
2шт.
42
150259C1
SHIELD, beater, 36, 38 and 40 inch row spacing
2шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
8шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
8шт.
43
939126R91
COVER ASSY, beater, 30 inch row spacing
2шт.
43
150347C91
COVER ASSY, beater, 36, 38 and 40 ich row spacing
2шт.
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
5/16 x 1/2 C-Z slt-truss-hd whiz lock
16шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16-18 C-Z flange whiz lock
16шт.
44
634468R1
SIDE, beater inner LH
1шт.
44
634467R1
SIDE, beater inner RH
1шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
8шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
8шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16-18 C-Z flange whiz lock
8шт.
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
SCRW, 5/16 x 1/2 C-Z slt-truss-hd whiz lock
8шт.
45
939132R1
SIDE, beater outer LH
1шт.
45
939133R1
SIDE, beater outer RH
1шт.
14994R1
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2
8шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex
8шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16-18 C-Z flange whiz lock
8шт.
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
5/16 x 1/2 C-Z slt-truss-hd whiz lock
8шт.
46
939148R2
HINGE, auger door LH, 30 inch row spacing
1шт.
46
150351C2
HINGE, auger door LH, 36, 38 and 40 inch row spacing
1шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16-18 C-Z flange whiz lock
1шт.
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
5/16 x 1/2 C-Z slt-truss-hd whiz lock
1шт.
47
939025R1
BRACKET, auger trough end support
2шт.
17412R1
BOLT,Hex, 3/8" - 16 x 3/4", Gr 2
3/8 x 3/4 hex-hd mach
4шт.
80280503
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd
BOLT, 3/8 x 1 sq-nk crg
4шт.
102635
NUT,3/8"-16, G5
8шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
8шт.
48
151328C1
SPACER, beater shaft inner, 36, 38 and 40 inch row spacing
2шт.
49
151315C1
SPACER, beater shaft bearing RH
2шт.
49
151327C1
SPACER, beater shaft bearing end, 30 inch row spacing
2шт.
50
155160C1
SUPPORT, beater section, 429WN serial no. 2813 and below, 430WN serial no. 801 and below
4шт.
50
166390C1
SUPPORT, beater section, 429WN serial no. 2814 and above, 430WN serial no. 1802 and above
4шт.
51
150232C1
ANGLE, auger trough front outer, 36 inch row spacing
2шт.
51
150233C1
ANGLE, auger trough front outer, 38 inch row spacing
2шт.
51
150234C1
ANGLE, auger trough front outer, 40 inch row spacing
2шт.
14995R1
BOLT
3/8 x 3/4 sq-nk crg
1шт.
102635
NUT,3/8"-16, G5
1шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
1шт.
52
939461R1
FLANGE
auger shaft bearing, for relube brg
4шт.
53
571425R1
FLANGED BEARING
auger shaft bearing, not relube brg
4шт.
14995R1
BOLT
3/8 x 3/4 sq-nk crg
6шт.
102635
NUT,3/8"-16, G5
6шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
6шт.
53
939147R1
HINGE, auger door center
1шт.
63226R1
SCREW, 5/16 x 1/2 C-Z slt-truss-hd whiz lock
7шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16-18 C-Z flange whiz lock
7шт.
54
939149R2
HINGE, auger door LH, 30 inch row spacing
1шт.
54
150352C2
HINGE, auger door RH, 36, 38 and 40 inch row spacing
1шт.
938017R1
FLANGE NUT,Flg, USR, 5/16"-18
5/16-18 C-Z flange whiz lock
1шт.
477-73108
SERRATED SCREW,Sl Truss Hd, 5/16" - 18 x 1/2"
5/16 x 1/2 C-Z slt-truss-hd whiz lock
1шт.
55
166045C1
ANGLE, auger adjustment, 429WN serial no. 2814 and above, 430WN serial no. 1802 and above
2шт.
18508R1
CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd
BOLT, 3/8 x 3/4 C-Z sq-nk crg
4шт.
120377
NUT,3/8" - 16, Gr 5
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
56
166048C1
BOLT, auger adjustment, 429WN serial no. 2814 and above, 430WN serial no. 1802 and above
2шт.
120377
NUT,3/8" - 16, Gr 5
4шт.
619856R1
WASHER
13/32 x 1 x 16 ga C-Z
4шт.
57
166046C1
BRACKET, auger bearing, 429WN serial no. 2814 and above, 430WN serial no. 1802 and above
2шт.
17351R1
CARRIAGE BOLT,Short Sq Nk, 3/8" - 16 x 1", Gr 2
BOLT, 3/8 x 1 C-Z sq-nk crg
8шт.
120377
NUT,3/8" - 16, Gr 5
8шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
8шт.
619856R1
WASHER
13/32 x 1 x 16 ga C-Z
8шт.
Выбрано товаров: 196
