Запчасти Case IH 430WN (F-17) - GATHERER DRIVE (58) - ATTACHMENTS/HEADERS

1

654275R1

HOUSING, gatherer drive brg

8шт.

179856

BOLT,Hex, 7/16" - 14 x 3/4", Gr 5

SCREW, 7/16-14 x 3/4 hex-hd cap

16шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

16шт.

2

586609R91

BALL BEARING

BEARING ASSY, gatherer drive ball

16шт.

3

555602R1

RING

gatherer drive brg snap

16шт.

4

936643R1

SPACER, gatherer drive brg

8шт.

5

156005C93

SPROCKET ASSY.

SPROCKET ASSY, gatherer chain drive 8T

4шт.

5

654276R92

SPROCKET ASSY, gatherer chain drive LH 8T, threaded

4шт.

161386C1

NUT

5/8-18 C-Z slt-hex jam

4шт.

6

156005C93

SPROCKET ASSY.

SPROCKET ASSY, gatherer chain drive 8T

4шт.

6

654277R92

SPROCKET ASSY, gatherer chain drive RH 8T, threaded

4шт.

161386C1

NUT

5/8-18 C-Z slt-hex jam

4шт.

7

654284R1

WASHER

gatherer driven shaft cup

8шт.

8

654283R1

THRUST WASHER

gatherer drive bevel gear

16шт.

9

156007C1

GEAR

gatherer driven bevel 18T, splined

8шт.

9

654280R1

PINION

GEAR, gatherer driven bevel LH threaded 18T, threaded

4шт.

9

654281R1

PINION

GEAR, gatherer driven bevel RH threaded 18T, threaded

4шт.

70119D

NUT

5/8-18 slt hex jam

6шт.

103387

COTTER PIN,1/8" x 1 1/2"

Pin, Split (Cotter), 1/8" x 1 1/2"

6шт.

575810R1

WASHER

21/32 x 1-1/2 x 11 ga

6шт.

10

654338R1

THRUST WASHER

gatherer driven shaft

8шт.

11

939106R91

SHAFT ASSY, gatherer drive outer

2шт.

12

935611R1

PINION

GEAR, gatherer drive bevel 18T

8шт.

13

118000

WOODRUFF KEY,#27, 1/4" x 2 1/8", HT

KEY, 1/4 x 2-1/8 Woodruff 27

8шт.

14

156032C91

FLANGED BEARING

HOUSING W/BRG, gatherer drive outer, for relube brg

8шт.

14

654289R11

HOUSING ASSY.

HOUSING W/BEARING, gatherer drive outer, not relube bearing

8шт.

NLS

NO LONGER SERVICED

16шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

16шт.

15

455102R11

COLLAR

W/SET SCREW, gatherer drive brg lkg

8шт.

83-1254

SET SCREW,Hex Soc, 1/4"-20 x 1/4"

SCREW, 1/4 x 1/4 hex-soc-hd cup-pt set

8шт.

16

654288R1

SHIM, gatherer drive bevel gear

16шт.

17

939109R91

SHAFT ASSY, gatherer drive inner coupling, 30 inch row spacing

2шт.

17

150296C91

SHAFT ASSY, gatherer drive inner coupling, 36 inch row spacing

2шт.

17

150294C91

SHAFT ASSY, gatherer drive inner coupling, 38 inch row spacing

2шт.

17

150292C91

SHAFT ASSY, gatherer drive inner coupling, 40 inch row spacing

2шт.

18

939108R1

COUPLING

gatherer drive outer shaft female

2шт.

19

117987

KEY

1/4 x 2-1/4 Woodruff 27

2шт.

20

589595R91

SHAFT ASSY, gatherer drive outer coupling, 36 inch row spacing

1шт.

20

589593R91

SHAFT ASSY, gatherer drive outer coupling, 30 and 38 inch row spacing

2шт.

20

589594R91

SHAFT ASSY, gatherer drive outer coupling, 40 inch row spacing

2шт.

21

589600R1

SPROCKET, gatherer driven 24T

2шт.

17446R1

BOLT,3/8" - 16 x 1 1/4", Gr 2

3/8 x 1-1/4 hex-hd mach

8шт.

102635

NUT,3/8"-16, G5

8шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

8шт.

22

455102R11

COLLAR

W/SET SCREW, outer coupling shaft lkg

2шт.

83-1254

SET SCREW,Hex Soc, 1/4"-20 x 1/4"

SCREW, 1/4 x 1/4 hex-soc-hd cup-pt set

2шт.

23

937518R91

FLANGE

W/STR LUB FITTING, brg, for relube brg

2шт.

23

571424R1

FLANGE

gatherer outer coupling shaft bearing, not relube brg

2шт.

24

582389R91

DRIVE SPROCKET

SPROCKET, gatherer drive idler 15T, 429WN serial no. 2228 and below, 430WN serial no. 1521 and below

2шт.

15146R1

BOLT, 5/8 x 3 sq-nk crg

2шт.

102639

NUT,5/8"-11, G5

2шт.

103325

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

12258R1

WASHER

21/32 x 1-1/4 x 11 ga

2шт.

10620P

WASHER

21/32 x 1-1/2 x 16 ga

2шт.

575810R1

WASHER

21/32 x 1-1/2 x 11 ga

8шт.

Q1595

WASHER, 21/32 sq x 1-3/4 x 12 ga

4шт.

25

654164R91

CHAIN (AG)

CHAIN W/FLIGHTS, gatherer

8шт.

26

935619R91

GATHERING CHAIN

CHAIN, gatherer section roller

1шт.

27

587371R92

NO LONGER SERVICED

LINK, gatherer roller chain connecting

1шт.

28

450423R1

DRAG LINK

LINK, gatherer roller chain

1шт.

29

937173R1

GUIDE, gatherer chain LH

4шт.

17426R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 hex-hd mach

4шт.

102635

NUT,3/8"-16, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

30

937174R1

GUIDE, gatherer chain RH

4шт.

17426R1

BOLT,Hex, 3/8" - 16 x 1", Gr 2

3/8 x 1 hex-hd mach

4шт.

102635

NUT,3/8"-16, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

31

589922R3

GUIDE, gatherer chain holddown LH

4шт.

15007R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G2

28шт.

9635082

NUT,5/16" - 18, Gr 5

5/16-18 hex

28шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

28шт.

Q397

WASHER

11/32 x 3/4 x 16 ga

2шт.

32

589923R3

GUIDE, gatherer chain holddown RH

4шт.

15007R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G2

28шт.

9635082

NUT,5/16" - 18, Gr 5

5/16-18 hex

28шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

28шт.

Q397

WASHER

11/32 x 3/4 x 16 ga

2шт.

33

632172R91

SHAFT ASSY, gatherer carrier

8шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

16шт.

102635

NUT,3/8"-16, G5

16шт.

425-1414

JAM NUT,Jam, 7/8"-9, G5

16шт.

18549R1

NUT,7/8"-9, GB

7/8-9 ESNA stop

8шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

16шт.

103327

LOCK WASHER,7/8"

WASHER, LOCK, 7/8"

8шт.

615196R1

WASHER

29/32 x 1-3/4 x 11 ga

16шт.

Q1505

WASHER

13/32 x 1 x 16 ga

16шт.

34

654332R2

CARRIER, gatherer sprocket

8шт.

35

109461

LUBE NIPPLE,1/8"-27 x .66 lg

NIPPLE, LUBE, , PTF 1/8"-27 x .66 lg

8шт.

36

155915C91

DRIVE SPROCKET

SPROCKET, gatherer idler 8T, riveted

8шт.

36

654333R1

SPROCKET ASSY.

SPROCKET, gatherer idler 8T, for cast iron sprocket

8шт.

36

586156R91

BEARING

ASSY, gatherer idler sprocket ball, for cast iron sprocket

8шт.

36

357323R1

RING, SNAP

RING, gatherer idler sprocket brg snap, for cast iron sprocket

8шт.

36

935331R1

WASHER

gatherer idler sprocket cup, for cast iron sprocket

8шт.

36

586116R1

BOLT,Hex, 3/4" - 10 x 2 1/2"

gatherer idler sprocket, for cast iron sprocket

8шт.

586116R1

BOLT,Hex, 3/4" - 10 x 2 1/2"

3/4 x 2-1/2 hex-hd mach

8шт.

115554

LOCK WASHER,Int Tooth, 3/4"

WASHER, 3/4 int-tooth lock

8шт.

615168R1

WASHER

25/32 x 1-1/2 x 11 ga

24шт.

37

219-37

LUBE NIPPLE,45 Degree Elbow, 1/4" - 28 NPTF

FITTING, 1/4-28 NS 45 deg lube

8шт.

38

937517R1

FLANGE

gatherer outer coupling, for relube brg

1шт.

38

571424R1

FLANGE

gatherer outer coupling shaft, not relube bearing, brg

2шт.

14994R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G2

6шт.

9635082

NUT,5/16" - 18, Gr 5

5/16-18 hex

6шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

6шт.

39

632189R1

SPACER, gatherer carrier shaft

8шт.

40

544

CANVAS

SPRING, gatherer carrier shaft

8шт.

41

589856R1

SPACER, gatherer carrier shaft spring

8шт.

42

632185R1

BRACKET, gatherer carrier shaft LH

4шт.

42

632186R1

BRACKET, gatherer carrier shaft RH

4шт.

15108R1

BOLT, 3/8 x 2-1/2 sq-nk crg

8шт.

102635

NUT,3/8"-16, G5

8шт.

43

632183R11

BRACKET ASSY, gatherer support LH

4шт.

14995R1

BOLT

3/8 x 3/4 sq-nk crg

16шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

4шт.

102635

NUT,3/8"-16, G5

20шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

20шт.

44

632184R11

BRACKET ASSY, gatherer support RH

4шт.

14995R1

BOLT

3/8 x 3/4 sq-nk crg

16шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

4шт.

102635

NUT,3/8"-16, G5

20шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

20шт.

45

632180R1

BRACE, divider outer LH

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

3шт.

102635

NUT,3/8"-16, G5

3шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

46

632181R1

BRACE, divider outer RH

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

3шт.

102635

NUT,3/8"-16, G5

3шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

3шт.

47

CHAIN, gatherer drive LH roller, use 81 links of 3/4 in roller chain from 10-ft rolls marked 1793D, 1 connecting link 1786D, 1 offset link

1шт.

47

CHAIN, gatherer drive RH roller, use 65 links of 3/4 in roller chain from 10-ft rolls marked 1793D, 1 connecting link 1786D

1шт.

48

482303R91

BALL BEARING,1.0005" ID x 52 mm OD x 0.8434"

BEARING ASSY, gatherer outer coupling shaft relube ball

1шт.

48

455965R91

BALL BEARING,1.0005" ID x 52 mm OD x 15 mm

ASSY, gatherer outer couling shaft ball, not relube brg

2шт.

49

654385R1

SPACER,26.21mm ID x 31.75mm OD x 19.05mm L

gatherer drive brg outer

8шт.

50

654948R91

SHAFT ASSY, gatherer drive inner

2шт.

51

161069C1

SPROCKET, gatherer chain slow speed special 28T, 3.44 mph

2шт.

51

161070C1

SPROCKET, gatherer chain slow speed special 30T, 3.00 mph

2шт.

52

166019C1

BRACKET, gatherer drive tightener, 429WN serial no. 2229 and above, 430WN serial no. 1522 and above

2шт.

18508R1

CARRIAGE BOLT,Short Nk, 3/8" - 16 x 3/4", Gr 2, Full Thd

BOLT, 3/8 x 3/4 C-Z sq-nk crg

4шт.

120377

NUT,3/8" - 16, Gr 5

4шт.

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

53

583620R1

BLOCK

gatherer drive tightener, 429WN serial no. 2229 and above, 430WN serial no. 1522 and above

2шт.

12872R1

BOLT,Short NK, 5/16"-18 x 1", G2, Full Thd

CARRIAGE, Short NK, 5/16"-18 x 1", G2, Full Thd

2шт.

120376

NUT,5/16"-18, G5

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.
