Запчасти Case IH 429WN (F-12) - STALK ROLL FRAME, ROLLS AND DRIVE (58) - ATTACHMENTS/HEADERS

1

632198R91

SHIELD ASSY, stalk roll LH

4шт.

2

632199R91

PLATE

SHIELD ASSY, stalk roll RH

4шт.

3

654952R91

CONTROL ASSY, stalk roll shield

8шт.

4

589460R1

BOLT, stalk roll shield adjusting

8шт.

102635

NUT,3/8"-16, G5

16шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

8шт.

5

939101R1

LEVER, adjusting lower LH

4шт.

576483R1

LOCK PIN,5/16" x 1 1/2", Slotted

Pin, 5/16" x 1 1/2", Slotted

4шт.

6

589457R1

SCREW, adjusting nut retainer

16шт.

103325

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

16шт.

7

939102R1

LEVER, adjusting lower RH

4шт.

576483R1

LOCK PIN,5/16" x 1 1/2", Slotted

Pin, 5/16" x 1 1/2", Slotted

4шт.

8

589453R1

SCREW, shield adjusting LH-thd

4шт.

9

589454R1

SCREW, shield adjusting RH-thd

4шт.

10

935560R1

NUT, shield adjusting LH-thd

4шт.

11

935561R1

NUT, shield adjusting RH thd

4шт.

12

939103R1

SHAFT, shield adjusting, 30 inch row spacing

2шт.

12

589458R1

SHAFT, shield adjusting, 36, 38 and 40 inch row spacing

2шт.

13

M5895

COLLAR, shield adjusting shaft

4шт.

14

589725R91

CRANK ASSY, shield adjusting

1шт.

517843R1

COTTER PIN

PIN, 3/16 quick attachable cot

1шт.

15

632110R91

FRAME ASSY, stalk roll

4шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

13шт.

NLS

NO LONGER SERVICED

7/16 hex

23шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

23шт.

16

939065R91

BRACKET ASSY, roll chain tightener, 429WN & 430WN serial no. 501 and below

2шт.

16

155443C91

BRACKET ASSY, roll chain tightener LH

1шт.

16

155444C91

BRACKET ASSY, roll chain tightener RH, 429WN & 430WN serial no. 502 and above

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

4шт.

102635

NUT,3/8"-16, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

17

939055R92

BRACKET ASSY, frame support

4шт.

14995R1

BOLT

3/8 x 3/4 sq-nk crg

12шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

1шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

10шт.

111-404

CARRIAGE BOLT,Short NK, 7/16"-14 x 1 1/4", G5

BOLT, 7/16 x 1-1/4 sq-nk crg

2шт.

9635082

NUT,5/16" - 18, Gr 5

5/16-18 hex

2шт.

102635

NUT,3/8"-16, G5

12шт.

NLS

NO LONGER SERVICED

7/16-14 hex

24шт.

84896

SCREW,Slotted Truss Hd, 5/16" - 18 x 3/4"

5/16-18 x 3/4 truss hd std mach

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

24шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

12шт.

575807R1

WASHER

13/32 x 1 x 11 ga

8шт.

18

654945R1

BRACKET, frame brace right

1шт.

18

654944R1

BRACKET, frame brace left

1шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

4шт.

NLS

NO LONGER SERVICED

7/16-14 hex

4шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

4шт.

19

150065C1

ANGLE, stalk roll frame brace LH

1шт.

19

150066C1

ANGLE, stalk roll frame brace RH

1шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

4шт.

NLS

NO LONGER SERVICED

7/16-14 hex

4шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

4шт.

20

654943R1

STRAP, stalk frame anchor, 6 used 30 inch row spacing/4 used 36, 38 & 40 inch row spacing

1шт.

88707

CARRIAGE BOLT,Sht Sq Nk, 1/2" - 13 x 1 1/4", Gr 5, Full Thd

BOLT, CARRIAGE, Short NK, 1/2"-13 x 1 1/4", G5, Full Thd

8шт.

102637

NUT,1/2"-13, G5

8шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

8шт.

21

939059R1

STRAP, stalk frame

3шт.

21

654942R1

STRAP, stalk frame, 36, 38 and 40 inch row spacing

3шт.

15010R1

CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2

BOLT, 1/2 x 1 sq-nk crg

12шт.

102637

NUT,1/2"-13, G5

12шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

12шт.

27

654947R1

BRACKET, stalk shield control

6шт.

86508749

CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5

BOLT, 3/8 x 1-1/4 sq-nk crg

18шт.

102635

NUT,3/8"-16, G5

18шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

18шт.

23

654290R91

ROLL ASSY, left driver stalk

2шт.

23

654291R91

ROLL ASSY, right driver stalk

2шт.

23

654292R91

ROLL ASSY, left driven stalk

2шт.

23

654293R91

ROLL ASSY, right driven stalk

2шт.

19638R1

LOCK NUT,3/4"-16, GB

NUT, 3/4 znp nylon insert

8шт.

178137

WASHER, 1-3/16 med lock

8шт.

24

654298R1

VALVE BLOCK

SECTION, stalk roll no 1

16шт.

181426

BOLT,Hex, 1/2" - 20 x 7/8", Gr 5

SCREW, 1/2-20 x 7/8 hex-hd cap

48шт.

115551

LOCK WASHER,Int Tooth, 1/2"

WASHER, LOCK, Int Tooth, 1/2"

48шт.

25

654299R1

VALVE BLOCK

SECTION, stalk roll no 2

16шт.

181426

BOLT,Hex, 1/2" - 20 x 7/8", Gr 5

SCREW, 1/2-20 x 7/8 hex-hd cap

48шт.

115551

LOCK WASHER,Int Tooth, 1/2"

WASHER, LOCK, Int Tooth, 1/2"

48шт.

26

935627R2

LUG

stalk roll LH

8шт.

26

935628R2

LUG

stalk roll RH

8шт.

27

654296R1

SEAL ASSY.

SECTION, stalk roll front

24шт.

134909

WASHER

RIVET, 5/16 x 2-1/4 F-HD solid

192шт.

28

589813R1

BUSHING

stalk roll front

16шт.

29

654297R1

WASHER

stalk roll shaft

8шт.

30

153748C11

HOUSING W/BRG, stalk roll, for relube brg

4шт.

30

585899R1

PLATE ASSY.

PLATE, stalk roll brg, not relube brg

6шт.

30

455103R91

BEARING

ASSY, stalk roll rear ball, not relube brg

2шт.

15009R1

CARRIAGE BOLT,Short Sq Nk, 7/16" - 14 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 7/16"-14 x 1", G2, Full Thd

16шт.

NLS

NO LONGER SERVICED

7/16-14 hex

16шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

16шт.

31

151313C1

SHIELD, stalk roll drive sprocket

2шт.

32

CHAIN, stalk roll drive roller, 30 inch row spacing, order 131 links of 3/4 pitch std roller chain from 10-ft roll marked 1793D and one connecting link 1786D

1шт.

32

CHAIN, stalk roll drive roller, 38 inch row spacing, order 137 links of 3/4 pitch std roller chain from 10-ft roll marked 1793D, and one connecting link 1786D

1шт.

32

CHAIN, stalk roll drive roller, 40 inch row spacing, order 143 links of 3/4 pitch std roller chain from 10-ft roll marked 1793D one connecting link 1786D and two offset links 1318D

1шт.

32

CHAIN, stalk roll drive roller, 36 inch row spacing, order 127 links of 3/4 pitch std roller chain from 10-ft roll marked 1793D, one connecting link 1786D and two offset links 1318D

1шт.

33

589854R91

BRACKET

SUPPORT ASSY, stalk roll left, 429WN serial no. 1908 and below, 430WN serial no. 1500 and below

4шт.

33

158779C91

SUPPORT ASSY, stalk roll left, 429WN serial no. 1909 and above, 430WN serial no. 1501 and above

4шт.

25-118

NUT,1/2"-20, G5

1/2-20 hex

4шт.

14-860

BOLT,Hex, 1/2" - 20 x 3-3/4", Gr 5

SCREW, 1/2-20 x 3-3/4 hex hd cap

4шт.

115551

LOCK WASHER,Int Tooth, 1/2"

WASHER, LOCK, Int Tooth, 1/2"

8шт.

34

332040

LUBE NIPPLE,90 Degree, 1/8" NPT x .84" lg

FITTING, 1/8-27 90 deg lub

8шт.

35

589853R91

BRACKET

SUPPORT ASSY, stalk roll right, 429WN serial no. 1908 and below, 430WN serial no. 1500 and below

4шт.

35

158780C91

SUPPORT ASSY, stalk roll right, 429WN serial no. 1909 and above, 430WN serial no. 1501 and above

4шт.

25-118

NUT,1/2"-20, G5

1/2-20 hex

4шт.

118445

SCREW, 1/2-20 x 3-3/4 hex-hd cap

4шт.

115551

LOCK WASHER,Int Tooth, 1/2"

WASHER, LOCK, Int Tooth, 1/2"

8шт.

36

629972R91

DRIVE SPROCKET,15T

SPROCKET W/BRG STALK ROLL DRIVE TIGHTENER

2шт.

15192R1

BOLT, 5/8 x 3-3/4 sq-nk crg

2шт.

102639

NUT,5/8"-11, G5

2шт.

103325

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

2шт.

551177R1

WASHER

21/32 x 1-1/4 x 16 ga

2шт.

12258R1

WASHER

21/32 x 1-1/4 x 11 ga

12шт.

PO12898

WASHER

21/32 x 1-1/2 x 11 ga

2шт.

37

150277C1

BOLT, drive chain adjusting, 38 and 40 inch row spacing

2шт.

37

939071R1

BOLT, drive chain adjusting, 30 and 36 inch row spacing

2шт.

114505

JAM NUT,Jam, 1/2"-13, G5

4шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

38

16964R91

FITTING

1/4-28 90 deg lub

8шт.

39

586318R1

PINION

SPROCKET, stalk roll driven 13T

4шт.

40

589696R1

BUSHING

SPACER, stalk roll driven sprocket

4шт.

41

580849R1

PINION

GEAR, stalk roll drive 20T

8шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

2шт.

125-10003

NUT,3/8"-16, G5, LH

3/8-16 hex

2шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

2шт.

42

585964R1

BUSHING

WASHER, stalk roll gear

8шт.

43

589406R1

ANGLE, drive chain guide, 4 used 30 inch row spacing, 2 used 36, 38 and 40 inch row spacing

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8-16 x 1 sq-nk crg

1шт.

125-10003

NUT,3/8"-16, G5, LH

3/8-16 hex

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

44

939069R1

GUIDE, stalk roll drive chain, 30 inch row spacing

2шт.

44

589407R1

GUIDE, stalk roll drive chain, 36, 38 and 40 inch row spacing

2шт.

15022R1

BOLT,Sht Sq Nk, 5/16" - 18 x 1 1/4"

5/16 x 1-1/4 sq-nk crg

1шт.

9635082

NUT,5/16" - 18, Gr 5

5/16-18 hex

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

45

583619R1

BLOCK

drive chain left tightener

1шт.

45

583620R1

BLOCK

drive chain right tightener

1шт.

15007R1

CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 1", Gr 2

BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G2

2шт.

9635082

NUT,5/16" - 18, Gr 5

5/16-18 hex

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

46

939072R1

BRACKET, drive chain guide left

1шт.

46

939073R1

BRACKET, drive chain guide right

1шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

4шт.

102635

NUT,3/8"-16, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

47

150268C91

BRACE ASSY, stalk roll frame LH, 36, 38 and 40 inch row spacing

1шт.

47

150269C91

BRACE ASSY, stalk roll frame RH, 36, 38 and 40 inch row spacing

1шт.

15010R1

CARRIAGE BOLT,Short Sq Nk, 1/2" - 13 x 1", Gr 2

BOLT, 1/2 x 1 sq-nk crg

6шт.

102637

NUT,1/2"-13, G5

6шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

6шт.

48

152980C1

STRIP, stalk roll frame support filler

8шт.

80280503

CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5, Full Thd

BOLT, 3/8 x 1 sq-nk crg

16шт.

102635

NUT,3/8"-16, G5

16шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

16шт.

49

150357C1

BRACKET, stalk roll shield control outer

2шт.

86508749

CARRIAGE BOLT,Short Square Neck, 3/8" - 16 x 1 1/4", Grade 5

BOLT, 3/8 x 1-1/4 sq-nk crg

4шт.

102635

NUT,3/8"-16, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

50

156030C91

BEARING

ASSY, stalk roll rear relube ball

8шт.

51

SPROCKET, stalk roll drive 25T, refer to main drive listing section F

1шт.
