Запчасти Case IH 404 (14[1]) - LIFT RAM, 1750 PSI RELIEF VALVE KIT, 900 - 960 (58) - ATTACHMENTS/HEADERS

1

F91781

BRACKET - hydraulic valve, R.H. rear

1шт.

113-101

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

Lockwasher (192-20) Hex, 5/16"-18 x 1/2", G5, Full Thd

1шт.

113-118

BOLT,Hex, 5/16" - 18 x 5/8", Gr 5

Lockwasher (192-20) Hex, 5/16"-18 x 5/8", G5, Full Thd

2шт.

9635082

NUT,5/16" - 18, Gr 5

fl. washer (195-521) 5/16"-18, G5

2шт.

2

F91783

BRACKET - hydraulic valve, R.H. front (900)

1шт.

3

F91782

BRACKET - hydraulic valve, R.H. front (960)

1шт.

4

F13237

PLATE - end

1шт.

F84832

KIT - "O'" ring (For ref. 4)

1шт.

5

F87195

LOCK VALVE

VALVE - relief, 1750 PSI

1шт.
