Запчасти Case IH 3020-30 (88.058.19) - DIA KIT, CROP LIFTERS AND SUPPORT (88) - ACCESSORIES

Схема запчастей Case IH 3020-30 - (88.058.19) - DIA KIT, CROP LIFTERS AND SUPPORT (88) - ACCESSORIES
2
1
11
1
3
1
1
12
1
1
1
1
1
1
6
5
5
3
1
4
6
1
7
10
9
4
home
8

Артикул

Название

Примечание

Количество

1

84160118

DIA KIT, HARVESTER

Crop Lifter, 20 And 25 Foot Header, Inc. 2-6, 8

1шт.

1

84134170

DIA KIT, HARVESTER

Crop Lifter, 30 Foot Header, Inc. 3-8

1шт.

1

84143555

DIA KIT, HARVESTER

Crop Lifter, 35 Foot Header, Inc.2-6, 8

1шт.

2

87699398

SUPPORT

Crop Lifter, 25 And 35 Foot Header

2шт.

3

100016

NUT,M10 x 1.5, Cl 8

8шт.

4

140042

WASHER,11mm ID x 34mm OD x 3mm Thk

8шт.

5

43138

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8

8шт.

6

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

8шт.

7

84441549

SUPPORT

Crop Lifter, 30 Foot Header

2шт.

8

84134152

SERVICE KIT

20 And 25 Foot Header, Inc. 9-12

24шт.

8

84134152

SERVICE KIT

30 Foot Header, Inc. 9-12

29шт.

8

84134152

SERVICE KIT

35 Foot Header, Inc. 9-12

34шт.

9

84134059

CROP LIFTER

1шт.

10

140045

BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk

1шт.

11

374892

CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8

1шт.

12

9514326

NUT

M10

1шт.

Выбрано товаров: 16
