Запчасти Case IH 3020-20 (88.058.12[02]) - CUTTER BAR REBUILD KIT STUB DRIVE SINGLE DRIVE 20 FT W/KNIFE (88) - ACCESSORIES

1

47762854

KIT

Incl 2 - 19

1шт.

2

84409315

GUARD

1шт.

3

84409304

GUARD

3шт.

4

84409307

GUARD

36шт.

5

84395857

SHIM,33mm OD x 2.1mm Thk

56шт.

6

84409311

KNIFE CLIP

3шт.

7

84396057

KNIFE CLIP

36шт.

8

84409309

ADJUSTING PLATE

4шт.

9

84409313

KNIFE CLIP

1шт.

10

84396059

STEEL PLATE

36шт.

11

84396061

SHIM,31mm OD x 3.25mm Thk

40шт.

12

84245171

GUARD

1шт.

13

86512426

CARRIAGE BOLT,Sq Nk, M10 x 50mm, Cl 8.8

2шт.

14

100037

LOCK NUT,M10 x 1.5, Cl 8

82шт.

15

87742342

PLOW BOLT,M10 x 1.5 x 30mm, Class 10.9

40шт.

16

86619802

FLANGE NUT,M10 x 1.5, Cl 8

40шт.

17

86512425

CARRIAGE BOLT,Sq Nk, M10 x 45mm, Cl 8.8

80шт.

18

83904166

WASHER,10.5mm ID x 30mm OD x 4mm Thk

1шт.

19

47601030

KNIFE ASSY

1шт.

The Knife Head does not have the Connecting Block. Need to Reuse Old, or Order the one Needed (M12 or M16 holes).

1шт.
