Артикул
Название
Примечание
Количество
1
87784C92
HYDRAULIC OIL FILTER
Hydraulic
2шт.
See Figure 08-04
1шт.
2
217-355
FITTING,90 Degree Elbow, 1-1/4" Hose Barb x 1-5/8" - 12 Male ORB
Includes 3
2шт.
3
238-6020
O-RING,0.07" Thk x 0.864" ID, -20, Cl 6, 90 Duro
1шт.
4
198617A2
ELBOW
Special, Inc. 5
1шт.
5
237-6020
O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro
1шт.
6
1989349C3
HOSE
270 mm (10-5/8 in), Cut From 1541953C1
2шт.
See Figure 08-01
1шт.
7
214-3232
HOSE CLAMP,1-1/4" - 2-1/8", HD Worm, W/ Liner
2шт.
8
408847A1
HOSE
450 mm (17-3/4 in), Cut From 1541953C1
1шт.
See Figure 06-04
1шт.
9
201-306
90 ELBOW,90 Degree Elbow, 1" - 14 Male ORFS x 7/8" - 14 Male ORB
Inc. 10,11
1шт.
10
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
11
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
12
399768A1
HOSE ASSY.
685 mm (26-31/32 in)
1шт.
See Figure 08-05
1шт.
13
201-316
ELBOW,45 Degree Elbow, 1" - 14 Male ORFS x 7/8" - 14 Male ORB
Inc. 14, 15
1шт.
14
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
15
238-6016
O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro
1шт.
16
187671A1
HOSE
1985 mm (78-1/8 in)
1шт.
See Figure 07-02
1шт.
17
201-414
TEE,1 11/16"-12 x 1 5/8"-12 Run, ORFS
1-11/16 Or x 1-5/16 Or, Inc. 18, 19
1шт.
19
237-6020
O-RING,0.118" Thk x 1.475" ID, -920, Cl 6, 90 Duro
1шт.
20
201-144
REDUCER,1 3/16"-12 Male x 1 11/16"-12 Fem, ORFS
1-1/4 Or x 3/4, Inc. 21, 22
1шт.
21
238-6018
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
1шт.
23
203-906
TUBE NUT,1 11/16"-12 ORFS
1шт.
24
390565A1
TUBE,1" OD, 1510, 252 mm Length
Air Screen Return
1шт.
26
1546025C1
CLAMP
2 Piece
3шт.
27
1347127C1
PLATE
3шт.
28
413-596
BOLT,Hex, 5/16" - 18 x 6", Gr 5
2шт.
29
425-285
FLANGE NUT,Flg, 5/16"-18, G5
2шт.
30
390566A2
TUBE
Filter Return
1шт.
31
201-428
TEE,1-3/16" - 12 ORFS x 1-3/16" - 12 ORFS x 1-1/16" - 12 ORB
Incl. 32, 33
1шт.
32
238-6018
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
2шт.
33
237-6012
O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro
1шт.
34
201-417
TEE,1-3/16" - 12 JIC x 1-3/16" - 12 ORFS x 1-3/16" - 12 ORFS
Inc. 35
1шт.
35
238-6018
O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro
2шт.
36
203-904
TUBE NUT,1 3/16"-12 ORFS
1шт.
37
201-143
REDUCER,11/16"-16 Male x 1 3/16"-16 Fem, ORFS
Inc. 38
1шт.
39
87445254
MANIFOLD VALVE
1шт.
See Figure 08-22
1шт.
40
129096A1
HOSE
735 mm (29 in), Cut From 1977295CX
2шт.
41
214-1412
HOSE CLAMP,#12, 0.69" - 1.25", Type F Worm
2шт.
42
300278A1
BRACKET
Filter Mounting
1шт.
43
413-610
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5
6шт.
44
492-11038
LOCK WASHER,3/8"
10шт.
45
413-616
BOLT,Hex, 3/8" - 16 x 1", Gr 5
4шт.
46
425-106
NUT,3/8"-16, Cl 5
4шт.
Выбрано товаров: 52
