Запчасти Case IH CPX420 (09A-23[01]) - KIT PIVOT (13) - PICKING SYSTEM

1

B95501

KIT

Incl 2 - 6

1шт.

2

83990583

LOCK WASHER,M8 x 14.8mm OD x 2.1mm Thk

2шт.

3

669815R3

BUSHING,19.16mm ID x 28.78mm OD x 20.62mm L

1шт.

4

322358

BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk

2шт.

5

214910C2

PIVOT

1шт.

6

20677

BOLT,Hex, 5/16" - 24 x 5/8", Gr 5, Full Thd

2шт.
