Артикул
Название
Примечание
Количество
1
230-46318
LOCK NUT,1 1/8"-12, GA
2шт.
2
495-81190
WASHER,1.16" ID x 1.75" OD x 0.12" Thk
2шт.
3
1988758C1
HUB
Rotor Wrench
2шт.
4
87424376
CAP
Drum Clutch Speed Sensor
2шт.
5
1984289C4
RATCHET
Reverse, Left Hand, For Repair Kit Components See Ref. 54 - 57
1шт.
6
1984290C4
RATCHET
Reverse, Right Hand, For Repair Kit Components See Ref. 54 - 57
1шт.
7
219-1
LUBE NIPPLE,1/8" - 27 NPTF
2шт.
8
424-616
BOLT,Hex, 3/8" - 16 x 1", Gr 2
8шт.
9
492-11038
LOCK WASHER,3/8"
1шт.
10
1339217C1
GEAR
160T, Inc. 10A
2шт.
10a
1982410C1
BUSHING,57.25mm ID x 66.79mm OD x 18.74mm L
1шт.
11
1982414C1
SPROCKET ASSY.
Monitor Pickup
2шт.
12
116021A1
GEAR
104T, Spindle Drive
2шт.
14
102-23283
SNAP RING,#283, 3.009", Int, Spiral
No. 283, Internal Spiral
2шт.
15
87424378
SPACER,31.78mm ID x 48mm OD x 18mm L
Drum Rotor Speed Sensor
2шт.
16
87328624
JAM NUT
5/16 Stainless
8шт.
17
201118C91
BEARING ASSY,65mm ID x 100mm OD x 18mm W
Cam Center
2шт.
18
100-11255
SNAP RING,#255, Ext
2шт.
19
394252A1
CAM
Left Hand
1шт.
19
394253A1
CAM
Right Hand, Not Illustrated
1шт.
20
672448R2
SPACER
Inner Bearing
2шт.
22
413-58
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
6шт.
24
95-61034
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
6шт.
29
1982635C2
BOLT
7шт.
30
892-11020
LOCK WASHER,M20
8шт.
31
1982636C2
BOLT
1шт.
32
495-11081
WASHER,3/4", SAE
4шт.
34
1982612C1
SUPPORT
Idler Retaining
1шт.
35
1982634C2
BOLT
5/8
2шт.
36
524598R91
BALL BEARING,20mm ID x 52mm OD x 15mm W
Idler Gear
4шт.
36
524598R91GV
BEARING
Value, Ball Bearing
4шт.
37
1982409C1
GEAR
Idler
2шт.
38
1982615C1
SPACER
Double Idler
2шт.
39
1982412C1
SPACER
Idler Gear
6шт.
40
1339309C1
GEAR
93T, Drum Drive
1шт.
41
524598R91
BALL BEARING,20mm ID x 52mm OD x 15mm W
Gear
1шт.
42
100-21206
SNAP RING,2.062", Int, #206
3шт.
43
1982637C2
BOLT
1шт.
44
1982620C2
ANGLE BAR
Idler, Rear
1шт.
45
413-612
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
2шт.
46
495-11041
WASHER,0.406" ID x 0.812" OD x 0.065" W
4шт.
47
425-106
NUT,3/8"-16, Cl 5
2шт.
48
413-1064
BOLT,Hex, 5/8" - 11 x 4", Gr 5
2шт.
48
413-1040
BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5
2шт.
49
492-11062
BEARING WASHER,5/8"
4шт.
50
87424381
SUPPORT
Drive, Left Hand
1шт.
52
1339404C1
GEAR
56T, Doffer Drive
2шт.
51
87424380
SUPPORT
Drive, Right Hand
1шт.
53
524598R91
BALL BEARING,20mm ID x 52mm OD x 15mm W
Doffer Gear
2шт.
278799A1
REPAIR KIT
Inc. 54 - 57
1шт.
54
700703406
CAM
Ratchet
14шт.
55
700703408
SPRING
Detent
14шт.
56
800-2180
SNAP RING,M80, Int
1шт.
57
124088A1
RING
Ratchet
1шт.
60
394414A1
CLAMP,24mm ID
2шт.
61
413-58
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
4шт.
62
492-11038
LOCK WASHER,3/8"
2шт.
63
87424377
SUPPORT
Rotor Speed Sensor
1шт.
64
87426499
MAGNET
Magnet, Rotor Monitor
1шт.
65
87446500
NUT
Nut, Nylon 5/16
1шт.
67
492-11025
LOCK WASHER,1/4"
2шт.
68
87424379
BRACKET
Rotor Speed Sensor
2шт.
69
87326704
SENSOR
Reed Switch Drum Rotor, Inc. 16
2шт.
70
87448799
HARNESS
Rotor
1шт.
71
REF
INSTRUCTION
HINGE ASSY, Front Doffer Post w/Flap
1шт.
See Figure 04-27
1шт.
Выбрано товаров: 69
