Артикул
Название
Примечание
Количество
1
30460V
SPACER, belt tightner arm, replaces 18761H
4шт.
2
663887R91
PULLEY,203.2mm Idler Dia x 214.63mm OD x 48.42mm W
W/BEARING, fan idler
3шт.
17700R1
BOLT, 5/8 x 3-3/4 hex-hd mach
2шт.
15224R1
BOLT, 5/8 x 4-1/4 sq-nk crg
3шт.
102639
NUT,5/8"-11, G5
3шт.
103325
LOCK WASHER,5/8"
WASHER, LOCK, 5/8"
3шт.
657102R1
WASHER
21/32 x 1-1/4 x 3/16
2шт.
3
672639R91
EYEBOLT ASSY, fan idler adjusting
1шт.
120377
NUT,3/8" - 16, Gr 5
Esna stop 3/8"-16, G5
2шт.
4
672627R1
BELT
fan drive countershaft
1шт.
5
672637R2
PULLEY
fan drive countershaft
2шт.
6
670989R91
BEARING ASSY
ASSY, fan cross shaft LH
1шт.
18684R1
BOLT,Sht Sq Nk, 3/8" - 16 x 1 1/4", Gr 2
3/8 x 1-1/4 znd sq-nk crg
3шт.
120377
NUT,3/8" - 16, Gr 5
3шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
3шт.
7
20810R1
LUBE NIPPLE,#10-32 x .50" lg
FITTING, 10-32 NF str-lub
1шт.
8
672636R1
field ground, belt drive
1шт.
18778R1
SCREW,Hex, 3/8"-16 x 3/4", G2
BOLT, 3/8 x 3/4 znd hex-hd mach
1шт.
120377
NUT,3/8" - 16, Gr 5
1шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
1шт.
9
672642R1
fan drive
1шт.
18494R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8 x 1 C-Z hex-hd mach
1шт.
120377
NUT,3/8" - 16, Gr 5
4шт.
120382
LOCK WASHER,Helical Spring, 3/8"
WASHER, LOCK, 3/8"
4шт.
10
672826R91
BALL BEARING,30 mm ID x 62 mm OD x 24 mm
ASSY, cross shaft, replace 467512R91
2шт.
11
561088R1
SNAP RING,#244, 2.588", Int, Spiral
cross shaft pulley snap
1шт.
12
672635R91
CLUTCH
FIELD, fan electric clutch
1шт.
13
672626R1
fan drive
1шт.
14
672632R1
fan drive electric clutch
1шт.
15
672634R1
SHIELD
ROTOR, fan electric clutch
1шт.
16
672633R1
SHIELD
ARMATURE, clutch, 10 inch
1шт.
179818
BOLT,Hex, 5/16" - 18 x 1", Gr 5
4шт.
9635082
NUT,5/16" - 18, Gr 5
5/16-18 hex.
4шт.
17
672630R2
STUD
drum drive pulley
4шт.
102637
NUT,1/2"-13, G5
4шт.
103323
LOCK WASHER,1/2"
WASHER, LOCK, 1/2"
4шт.
21796R1
WASHER
21/32 x 1 x 16 ga C-Z (or as required)
8шт.
18
672629R1
electric clutch pulley brg
1шт.
19
672628R1
cross shaft
1шт.
20
673807R1
SPACER, fan cross shaft
2шт.
21
672826R91
BALL BEARING,30 mm ID x 62 mm OD x 24 mm
ASSY, electric clutch field, replaces 467512R91
1шт.
22
672625R1
belt tightener outer
4шт.
18786R1
BOLT,Hex, 3/8"-16 x 3 1/2", G2
3/8 x 3-1/2 znd hex-hd mach
2шт.
18495R1
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 2
3/8 x 1-1/4 znd hex-hd mach
4шт.
664645R1
LOCK NUT,3/8"-16, GB
3/8-16 hex.
6шт.
21403R1
WASHER
13/32 x 1 x 11 ga C-Z
4шт.
23
672620R1
adjusting bracket anchor
4шт.
17426R1
BOLT,Hex, 3/8" - 16 x 1", Gr 2
3/8 x 1 hex-hd mach
8шт.
102635
NUT,3/8"-16, G5
8шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
8шт.
24
672619R1
adjusting bracket
2шт.
25
672621R91
SCREW
ASSY, idler adjustment
2шт.
26
219-8
LUBE NIPPLE,1/4" - 28 NPTF
NIPPLE, LUBE, , straight, drive type, Replaces 20691R1 1/4"-28 NPT x .54" lg
1шт.
27
66984D
WOODRUFF KEY,#126, 3/16" x 2 1/8", HT
3/16 x 2-1/8 Woodruff 126
2шт.
28
117987
KEY
1/4 x 2-1/8 Woodruff no. 27
1шт.
29
201739C91
SHAFT ASSY, fan cross, replaces 674981R1, composed of 1 Ref 14 hub 672632R1, 1 Ref. 18 spacer 672629R1, 2 Ref 20 spacers 673807R1
1шт.
18462R1
LOCK NUT,1"-14, GB
NUT, 1-14 elastic stop
2шт.
614451R1
WASHER
1-1/32 x 1-3/4 x 11 ga C-Z
2шт.
30
201753C91
NO LONGER SERVICED
BEARING ASSY, fan cross shaft RH, replaces 672827R91
1шт.
17452R1
BOLT,Hex, 1/2"-13 x 1 1/4", G2
1/2 x 1-1/4 znd hex-hd mach
2шт.
120378
NUT,Hex, 1/2" - 13, Gr 5
NUT, 1/2"-13, G5
2шт.
120384
WASHER,1/2"
LOCK, 1/2"
2шт.
178373R1
WASHER
17/32 x 1 x 16 ga C-Z
2шт.
31
668075R1
WASHER
fan idler
6шт.
32
561088R1
SNAP RING,#244, 2.588", Int, Spiral
electric clutch hub snap
1шт.
Выбрано товаров: 66
