Запчасти Case IH 414 (334) - COMPLETE SERVICE ENGINE (10) - ENGINE

Схема запчастей Case IH 414 - (334) - COMPLETE SERVICE ENGINE (10) - ENGINE

Артикул

Название

Примечание

Количество

318375R92

COMPLETE SERVICE ENGINE, Consists of all engine parts except the following, alternator generator, fan belt, fan blade, muffler and exhaust pipe

1шт.

345245R92

ENGINE

SKELETON SERVICE ENGINE, Consists of camshaft w/gear and bearings, connecting rods w/bearings, crankcase assembly, crankshaft w/bearings, gear and seals, oil pump, pistons w/pins and rings, rear bearing cap filler plugs, tappets

1шт.

530035R91

PACKAGE

GASKET SET, crankcase, Replaces 332652R91, Consists of

1шт.

369981R1

GASKET

breather pipe flange

1шт.

278268R1

GASKET

crankcase front cover

1шт.

278265R1

GASKET

crankcase front plate

1шт.

369984R1

GASKET

crankcase oil pan

1шт.

278347R1

GASKET

injection pump adaptor

1шт.

278270R2

GASKET

injection pump gear cover

1шт.

349039R1

GASKET

lubricating oil filter base

1шт.

601790C1

GASKET

lubricating oil filter base

1шт.

3405H

GASKET

lubricating oil pressure relief valve plug

1шт.

349038R1

GASKET

oil cooler manifold

1шт.

304854R1

RING

GASKET, oil filter case

1шт.

3405H

GASKET

oil pan drain plug

1шт.

353936R2

GASKET

oil pan shaft support

1шт.

69607R1

GASKET

oil pump body

1шт.

369982R1

GASKET

push rod cover

1шт.

251403R1

GASKET

relief valve plug

1шт.

69676R1

GASKET

water pump

1шт.

51527DC

GASKET

water trap

1шт.

350684R1

O-RING,0.139" Thk x 0.734" ID, -210, Cl 5, 75 Duro

oil cooler to manifold

2шт.

304012R1

GASKET

center tube

1шт.

312506R1

GASKET

crankcase front cover

1шт.

632851R1

GASKET

hydraulic gear pump

1шт.

254954R1

O-RING,0.139" Thk x 1.046" ID, -215, Cl 5, 75 Duro

pump adapter

1шт.

69674R1

GASKET

water pump plate

1шт.

310665R1

PLUG

rear bearing cap filler

2шт.

310446R95

GASKET KIT

GASKET SET, valve grinding, Consists of

1шт.

601509C1

GASKET

cylinder head

1шт.

278314R1

MANIFOLD GASKET

exhaust manifold center

2шт.

278313R2

GASKET

exhaust manifold ends

2шт.

305804R1

MANIFOLD GASKET

intake manifold

1шт.

278280R1

GASKET

thermostat housing

1шт.

278308R1

GASKET

valve cover

1шт.

446210

WASHER

valve cover

4шт.

347784R91

GASKET KIT

PACKAGE, fuel injection pump overhaul gasket, Consists of

1шт.

367979R1

GASKET

timing cover

2шт.

368012R1

SEAL

governor control cover

1шт.

346712R1

PLUG

end plate pipe

1шт.

603936C1

PLUG

end plate

1шт.

615768C1

CLIP

RING, flexible retaining

1шт.

304720R1

O-RING,0.139" Thk x 1.046" ID, -215, Cl 5, 75 Duro

SEAL, pilot tube oil

1шт.

304721R1

SEAL

pivot shaft

2шт.

304729R1

SEAL

low idle adjusting screw

1шт.

313288R1

SEAL

OIL SEAL, drive shaft

2шт.

319687R1

WIPER SEAL

piston hole plug

4шт.

319689R1

WIPER SEAL

advance screw hole plug

1шт.

346706R1

SEAL

1шт.

346709R1

SEAL

SEAL, element

1шт.

340214R1

SEAL

end plate plug

1шт.

352219R1

O-RING,0.07" Thk x 0.239" ID, -10, Cl 5, 75 Duro

SEAL, advance adjusting screw

5шт.

359158R1

O-RING,0.301" ID x 0.07" Width

-011, 70 Duro, .031" ID x .070" Thk, Head locating screw

4шт.

367982R1

O-RING,0.154" Width

SEAL, transfer pump

1шт.

368030R1

RING

SEAL, end plate sleeve

2шт.

368337R1

SEALING RING

SEAL, hydraulic head

1шт.

615142C1

SEAL

SEAL, regulating piston

1шт.

319744R1

WASHER

throttle shaft seal

2шт.

324791R1

SEAL ASSY.

WASHER, torque screw hole plug

1шт.

367984R1

SEALING WASHER

WASHER

12шт.

368014R1

WASHER

guide stud

1шт.

374544R94

KIT

PACKAGE, water pump service, Consists of

1шт.

69674R1

GASKET

water pump plate

1шт.

69676R1

GASKET

water pump

1шт.

387931R1

TORQ CONV IMPELLER

IMPELLER, water pump

1шт.

687161C91

PACKING

PACKAGE, water pump seal

1шт.

327316R1

SNAP RING,1.188", Int, #118

Ring, Snap, , brg 1.188", Int, #118

1шт.

684432C1

SEAT/SLOT

SEAT, water pump seal

1шт.

376602R91

BEARING ASSY,30mm OD x 110.69mm L

SHAFT & BEARING ASSY, water pump

1шт.

687161C91

PACKING

PACKAGE, water pump seal service, Replaces 701331C92, Consists of

1шт.

NSS

NOT SOLD SEPARAT

SEAL, water pump

1шт.

NSS

NOT SOLD SEPARAT

SEAT, water pump

1шт.

Выбрано товаров: 72
