Артикул
Название
Примечание
Количество
1
19502R1
ELBOW, 11/16-16 hi-duty tube fitting 45 deg, water outlet
1шт.
2
19987R1
NUT
11/16-16 hi-duty tube fitting
4шт.
3
379381R11
PIPE W/NUTS ASSY, water outlet
1шт.
4
19985R1
TUBE NUT,1/2"-20
NUT, 1/2-20 hi-duty tube fitting
2шт.
5
379380R1
PLATE, fuel regulator mounting
1шт.
179860
BOLT,Hex, 7/16" - 14 x 1 1/4", Gr 5
7/16 X 1-1/4 CAP SCREW
2шт.
277006R1
MOUNTING PLATE SPACER
2шт.
103322
LOCK WASHER,7/16"
WASHER, LOCK, 7/16"
2шт.
6
109563R1
ELBOW
90 deg flared
3шт.
7
18506R1
CONNECTOR, 11/16-16 hi-duty tube fitting male 1/2" NPT x 11/16"-16
1шт.
8
380917R11
PIPE W/NUTS ASSY, Serial Range: filter-regulator
1шт.
9
371100R91
REGULATOR ASSY, fuel, discontinued for service, For components see list of parts under details of fuel regulator
1шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 NUT
3шт.
179823
BOLT,Hex, 5/16" - 18 x 1 5/8", Gr 5
3шт.
23323H
SPACER,1/4" Pipe x 1/2"
REGULATOR MOUNTING SPACER
3шт.
10
68134D
ELBOW, 11/16-16 hi-duty tube fitting male pipe 90º x 1/2" NPT x 11/16"-16
2шт.
11
346818R91
FILTER ASSY, fuel, For components see list of parts under details of fuel filter
1шт.
9635082
NUT,5/16" - 18, Gr 5
5/16 NUT
2шт.
179817
BOLT,Hex, 5/16" - 18 x 7/8", Gr 5, Full Thd
2шт.
12
188902R1
NIPPLE, fuel hose
1шт.
13
311164C91
HOSE CLAMP,#20, 0.81/1.75 Type F Worm
CLAMP, fuel hose, Replaces 274086R91
2шт.
14
376584R1
HOSE, fuel line
1шт.
15
36521D
CONNECTOR, 3/8-24 hi-duty tube fitting
1шт.
16
19983R1
NUT, 5/16-24 hi-duty tube fitting
2шт.
17
376585R11
PIPE W/NUTS ASSY, balance
1шт.
18
376586R11
PIPE W/NUTS ASSY, idle
1шт.
19
24847H
ELBOW,90 Degree x 1/8" NPT x 1/2"-20
1/2-20 90 deg hi-duty tube fitting male pipe
2шт.
20
380587R92
CARBURETOR ASSY, For components see list of parts under details of carburetor
1шт.
179841
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
2шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
2шт.
21
32468H
ELBOW,90 Degree x 1/8" NPT x 3/8"-24
3/8-24 90 deg hi-duty tube fitting male pipe
1шт.
22
19983R1
NUT, 5/16-24 hi-duty tube fitting
2шт.
23
19272R1
TEE, 1/8 x 90 deg two-way
1шт.
24
188897R1
ELBOW, fuel hose
1шт.
25
376587R11
PIPE W/NUTS ASSY, water inlet
1шт.
26
138105
TEE,1/2" NPT, Fem
1/2 pipe
1шт.
27
141504
PIPE,Nipple, 1/2" NPT x 1 1/2"
NIPPLE, 1/2 x 1-1/2 close pipe
1шт.
18506R1
CONNECTOR, 11/16-16 hi-duty tube fitting male 1/2" NPT x 11/16"-16
1шт.
61387D
CLIP, choke
1шт.
Выбрано товаров: 41
