Запчасти Case IH 414 (266) - COMPLETE ENGINE (10) - ENGINE

376580R92

ENGINE ASSY, complete, Consists of all engine parts except the following, alternator generator, fan belt, fan blades, muffler and exhaust pipe

1шт.

394241R93

SKELETON SERVICE ENGINE, Consists of, C-263 40552MM and above

1шт.

CAMSHAFT W/GEAR AND BEARINGS

1шт.

CONNECTING RODS W/BEARINGS

1шт.

CRANKCASE ASSEMBLY

1шт.

CRANKSHAFT W/BEARINGS

1шт.

GEAR AND SEALS

1шт.

OIL PUMP

1шт.

PISTONS W/PINS AND RINGS

1шт.

TAPPETS

1шт.

387902R91

PACKAGE, crankcase gasket, 414 up to serial no. CH812E, 420 up to serial no. CH1371E, Consists of

1шт.

369981R1

GASKET

BREATHER PIPE GASKET

1шт.

312506R1

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

316156R1

CRANKCASE FRONT PLATE GASKET

1шт.

369984R1

GASKET

CRANKCASE PAN GASKET

1шт.

353936R2

GASKET

DISTRIBUTOR GASKET

1шт.

532496R1

GASKET

FUEL PUMP GASKET

1шт.

367669R1

GASKET

GOVERNOR HOUSING GASKET

1шт.

278270R2

GASKET

INJECTION PUMP HOLE COVER GASKET

1шт.

87351R1

GASKET

OIL FILLER CAP GASKET

1шт.

371238R1

GASKET

OIL FILTER BASE GASKET

1шт.

304854R1

RING

OIL FILTER CASE GASKET

1шт.

320273R91

GASKET

OIL FILTER CENTER TUBE GASKET PKG

1шт.

3405H

GASKET

OIL PAN DRAIN PLUG GASKET

1шт.

3405H

GASKET

OIL PRESSURE RELIEF VALVE CAP GASKET

1шт.

69607R1

GASKET

OIL PUMP COVER GASKET

2шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

OIL PUMP SCREEN-O-RING SEAL

1шт.

310665R1

PLUG

REAR BEARING CAP FILLER PLUG

2шт.

369982R1

GASKET

VALVE PUSH ROD COVER GASKET

1шт.

69676R1

GASKET

WATER PUMP GASKET

1шт.

69674R1

GASKET

WATER PUMP PLATE GASKET

1шт.

400899R92

SEAL PACKAGE

PACKAGE, crankcase gasket, 414CH813F to CH1568G, 420CH1372F to CH2820G, 416CH501H and above, 422CH501H and above, Consists of

1шт.

369981T1

BREATHER PIPE GASKET

1шт.

367574R1

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

378237R1

GASKET

CRANKCASE FRONT COVER GASKET

1шт.

398024R1

GASKET

CRANKCASE FRONT PLATE GASKET

1шт.

369984T1

CRANKCASE PAN GASKET

1шт.

353936R2

GASKET

DISTRIBUTOR GASKET

1шт.

384535R1

WASHER

ELEMENT, retaining washer grommet

1шт.

532496R1

GASKET

FUEL PUMP GASKET

1шт.

367669R1

GASKET

GOVERNOR HOUSING GASKET

1шт.

371238R1

GASKET

OIL FILTER BASE GASKET, For cast iron base

1шт.

384537R2

GASKET

OIL FILTER BASE GASKET, For use w/aluminum base

1шт.

534196R1

GASKET

OIL FILTER BASE GASKET, For spin-on filter base

1шт.

304854R1

RING

OIL FILTER CASE GASKET

1шт.

384532R1

GASKET

OIL FILTER CENTER TUBE GASKET

1шт.

3405H

GASKET

OIL PAN DRAIN PLUG GASKET

1шт.

3405H

GASKET

OIL PRESSURE RELIEF VALVE CAP GASKET

1шт.

69607R1

GASKET

OIL PUMP COVER GASKET

2шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

OIL PUMP SCREEN-O-RING SEAL

1шт.

310665R1

PLUG

REAR BEARING CAP FILLER PLUG

2шт.

369982R1

GASKET

VALVE PUSH ROD COVER GASKET

1шт.

69676R1

GASKET

WATER PUMP GASKET

1шт.

69674R1

GASKET

WATER PUMP PLATE GASKET

1шт.

304012R1

GASKET

OIL FILTER CENTER TUBE GASKET (NSS)

1шт.

632851R1

GASKET

hydraulic pump flange

1шт.

103364

PIN

RETAINING SPRING WASHER PIN

1шт.

372770R96

GASKET

PACKAGE, valve grinding gasket, Consists of

1шт.

530681R1

GASKET

carburetor

1шт.

368505R1

GASKET

water outlet

1шт.

164418R2

CYLINDER HEAD GASKET

cylinder head

1шт.

369983R2

GASKET

valve cover

1шт.

164420R1

GROMMET

valve cover

3шт.

85868R1

GASKET

intake to exhaust manifold

1шт.

400878R1

GASKET

intake & exhaust manifold

1шт.

111024R1

SEAL

intake valve stem

6шт.

866834R1

BAFFLE

SEAL, valve stem

12шт.

535166R1

RUBBER SEAL

intake valve stem

6шт.

374544R94

KIT

PACKAGE, water pump service, Consists of

1шт.

387931R1

TORQ CONV IMPELLER

IMPELLER, water pump

1шт.

684432C1

SEAT/SLOT

RETAINER AND SEAT, water pump seal

1шт.

73296R93

SEAL

ASSEMBLY, water pump, or

1шт.

687161C91

PACKING

SEAL PACKAGE, water pump

1шт.

376602R91

BEARING ASSY,30mm OD x 110.69mm L

SHAFT AND BEARING ASSY, water pump with slinger

1шт.

71351R1

SLINGER

water pump

1шт.

102069H

RING

RETAINER, bearing

1шт.

327316R1

SNAP RING,1.188", Int, #118

Ring, Snap, , brg 1.188", Int, #118

1шт.

69674R1

GASKET

water pump plate

1шт.

69676R1

GASKET

water pump

1шт.

387454R93

PACKAGE

carburetor gasket, gasoline, Consists of

1шт.

530681R1

GASKET

carburetor flange

1шт.

379598R1

SEAL

throttle shaft (NSS)

1шт.

18377D

GASKET

strainer screen retainer (NSS)

1шт.

25948D

GASKET

needle valve cage (NSS)

1шт.

47388DA

GASKET

fuel bowl (NSS)

1шт.

251583R1

WASHER

GASKET, metering nozzle (NSS)

1шт.

45149DA

SEAL

choke shaft dust (NSS)

1шт.

60947D

PLUG

PACKAGE, drip hole filler replacement

1шт.

24703DA

PACKING

fuel adjusting screw (NSS)

1шт.

381955R1

GASKET

fuel shut-off valve (NSS)

1шт.

384820R1

O-RING, fuel shut-off valve (NSS)

1шт.

387455R92

PACKAGE

carburetor overhaul, gasoline, Consists of

1шт.

1014457R1

INSTRUCTIONS, installing

1шт.

368139R91

SHAFT

& LEVER COMPLETE, throttle

1шт.

25484D

SPRING

RETAINER, idle throttle adjusting

1шт.

132128

SCREW, 10/32 x 7/8 fil-hd mach cd or zn-pltd Slotted Fil Hd, #10-32 x 7/8"

1шт.

47392D

SCREW

throttle butterfly

2шт.

362528R1

ADJUSTMENT SCREW

idle adjusting

1шт.

351959R1

SPRING

idle adjusting screw retainer

1шт.

57956D

PLUG

throttle shaft expansion

1шт.

47390D

BUSHING,7.91mm ID x 11.16mm OD x 12.7mm L

BEARING, throttle shaft

2шт.

29902DX

SCREEN

RETAINER ASSY, strainer screen

1шт.

47396DAX40

NEEDLE

CAGE ASSY, needle valve

1шт.

47395D

PIVOT

float lever

1шт.

47398DX

FLOAT

& LEVER ASSY

1шт.

45148D

SEAL,6.75mm ID x 11.24mm OD x 0.4mm Thk

RETAINER, dust seal

1шт.

351558R1

PIN, starting shutter stop

1шт.

52791R1

BALL,3/16" Dia, Stainless

friction spring

1шт.

46059D

SPRING

starting shutter friction

1шт.

374327R1

ADJUSTMENT SCREW,Sl Str Knurled Hd, 1/4" - 32 x 1.54", SST

fuel adjusting

1шт.

387444R93

PACKAGE, carburetor gasket, LP gas, Consists of

1шт.

359624R1

GASKET, gas inlet & economizer body

1шт.

379598R1

SEAL

throttle shaft dust

2шт.

64837D

SEAL, throttle shaft dust

1шт.

58899D

SEAL, choke dust

1шт.

128073R1

GASKET, air intake elbow

1шт.

66453H

GASKET

flange

1шт.

383376R1

GASKET

carburetor

1шт.

277369R91

PACKAGE, fuel regulator overhaul, LP gas, Composed of

1шт.

277367R91

DIAPHRAGM W/PIN, low pressure

1шт.

277370R91

DIAPHRAGM ASSY, high pressure

1шт.

64433D

GASKET, low pressure partition plate

1шт.

277198R1

GASKET, vaporizer cover

1шт.

277354R1

GASKET, high pressure valve spring retainer

1шт.

277351R1

LEVER, high pressure valve

1шт.

352221R1

O-RING,0.103" Thk x 0.549" ID, -113, Cl 5, 75 Duro

SEAL, low pressure valve

1шт.

359158R1

O-RING,0.301" ID x 0.07" Width

-011, 70 Duro, .031" ID x .070" Thk, High pressure valve

1шт.

277358R91

SEAT ASSY, high pressure valve

1шт.

37179D

SCREW, idle adjusting

1шт.

277199R1

SCREW, vaporizer partition plate

3шт.

19270R91

SCREW W/LOCK WASHER

23шт.

19271R91

SCREW W/LOCK WASHER

2шт.

277196R91

SPRING ASSY, high pressure

1шт.

277355R1

SPRING, high pressure valve

1шт.

277356R1

SPRING, high pressure valve seat retainer

1шт.

277360R1

SPRING, low pressure valve

1шт.

113434R91

STRAINER ASSY, fuel inlet

1шт.

277357R1

VALVE, high pressure

1шт.

277359R91

VALVE, high pressure (NSS)

1шт.

386010R91

KIT

PACKAGE, governor overhaul service, Consists of

1шт.

172530

PLUG,Exp, 11/16"

governor housing

1шт.

369593R1

BUSHING

governor

1шт.

369594R1

BUSHING

governor

1шт.

361123R91

OIL SEAL

OIL SEAL, governor rockshaft

1шт.

ST552

BALL BEARING,12mm ID x 37mm OD x 12mm W

BEARING, governor shaft ball

1шт.

281907C1

SNAP RING,1.438", Int, #143

Ring, Snap, , governor shaft brg 1.438", Int, #143

1шт.

367741R1

WEIGHT

governor

2шт.

17053R1

LOCK PIN,Sl Spring, 1/4" x 1 3/8"

PIN, , ESNA 1/4" x 1 3/8", Slotted

2шт.

387878R1

SLEEVE

governor thrust

1шт.

367656R12

ROCKSHAFT

LEVER AND ROCKSHAFT ASSY

1шт.

368938R1

SET SCREW,Hdls Hex Skt, 1/4" - 28 x 5/16", Cup Pt

governor thrust fork set

1шт.

367653R1

FORK

governor thrust

1шт.

374795R1

VALVE SPRING

SPRING, bumper

1шт.

393405R91

THRUST BEARING,11.07mm ID x 25.4mm OD x 11.13mm W

governor thrust ball

1шт.

367669R1

GASKET

governor housing

1шт.

362667R1

CLIP

cable harness, attaching, Serial Range: harness-crankcase

1шт.

180143

SCREW,Hex, 7/16" - 14 x 3/4"

7/16-14 x 3/4 znd hex-hd cap

1шт.

81547

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

1шт.

2753413R1

PRODUCT GRAPHIC

safety and operating instructions

1шт.

2752906R1

PRODUCT GRAPHIC

dry air cleaner instructions

1шт.
