Запчасти Case IH 414 (008) - RIGHT PICKER DRUM DRIVE (60) - PRODUCT FEEDING

1

10169RA

SPROCKET ASSY.

SPROCKET, water distributor drive (Units B and D)

1шт.

441012R1

LOCK PIN,1/4" x 7/8", Slotted

Pin, 1/4" x 7/8", Slotted

1шт.

2

70120D

SLOTTED NUT,7/8"-14

NUT, 7/8NF slt-hex jam (Units B and D)

1шт.

3

662503R11

SPROCKET ASSY.

SPROCKET, spindle and doffer drive (Riveted assembly) (Units B and D)

1шт.

4

10167R

SPROCKET, picker drum drive (Units B and D)

1шт.

11926R

SHIM

sprocket

3шт.

5

9617020

PLUG,1/4" - 18 x 0.48"

1/4" pipe (Units B and D)

1шт.

6

656140R1

HOUSING

picker drive (Units B and D)

1шт.

1/2 X 1-1/4" CAP SCREW

4шт.

1/2" LOCK WASHER

4шт.

7

659711R91

SEAL

OIL SEAL, picker drive sprocket shaft (Units B and D)

1шт.

8

ST205A

BEARING, BALL,35 mm ID x 72 mm OD x 17 mm

BEARING, picker drive pinion and sprocket (2 for units B and D)

1шт.

9

656165R1

SPACER

lower picker drive vertical shaft gear (Units B and D)

1шт.

10

656143R2

GEAR

picker drive (Units B and D)

1шт.

11

656164R1

SPACER

upper picker drive vertical shaft gear (Units B and D)

1шт.

12

10156R

SHIM

heavy picker drive gear (3 for units B and D)

1шт.

12

10157R

SHIM

light picker drive gear (3 for units B and D)

1шт.

13

ST213

BALL BEARING,30 mm ID x 62 mm OD x 16 mm

BEARING, upper picker drive sprocket shaft (Units B and D)

1шт.

14

70121D

NUT

1NF stl-hex jam (Units B and D)

1шт.

15

14R

RETAINER

uper right bearing (Units B and D)

1шт.

16

10164R

GASKET

bearing cap (Units B and D)

1шт.

16

656630R1

GASKET

bearing retainer (Units B and D)

1шт.

17

80710

LUBE NIPPLE,1/8” – 27 Dryseal PTF

NIPPLE, LUBE, (Units B and D) 1/8"-27 x .66 lg

1шт.

18

15R

CAP

picker drive shaft bearing (Units B and D)

1шт.

3/8 X 1-7/8" MACH BOLT

3шт.

3/8" LOCK WASHER

3шт.

19

656144R2

SHAFT

picker drive sprocket (Units B and D)

1шт.

1/8 X 1-3/8" COTTER PIN

1шт.

1/8 X 1-1/2" COTTER PIN

1шт.

29/32 X 1-1/2" X 22 GA WASHER

1шт.

20

114735

KEY, no. 16 Woodruff (Units B and D)

1шт.

21

10728P

PLUG

1/2" drilled pipe (Units B and D)

1шт.

22

656142R2

SHAFT

picker drive pinion (Units B and D)

1шт.

1-5/32 X 1-3/4" X 11 GA WASHER

1шт.

23

656163R1

SPACER

picker drive pinion (Units B and D)

1шт.

24

656166R1

SHIM

heavy picker drive pinion (3 for Units B and D)

1шт.

24

656167R1

SHIM

light picker drive pinion (3 for Unit B and D)

1шт.

25

ST247

BEARING, BALL,35 mm ID x 72 mm OD x 17 mm

BEARING, pinion shaft (Units B and D)

1шт.

26

M86688

SEAL

OIL SEAL, pinion shaft (Units B and D)

1шт.

27

656168R1

GASKET

pinion shaft bearing retainer (Units B and D)

1шт.

28

656141R1

RETAINER

picker drive pinion shaft bearing (Units B and D)

1шт.

3/8" X 1" MACH BOLT

3шт.

3/8" LOCK WASHER

3шт.

29

10176R

STRIP

WASHER, knuckle retainer (Units B and D)

1шт.

5/8NF X 1-1/4" CAP SCREW

1шт.

5/8" LOCK WASHER

1шт.

30

217-519

DRAIN PLUG,Sq Hd, 1/2"-14 NPTF

PLUG, , Pipe (2 for units B and D) Sq Hd, 1/2"-14 NPTF

1шт.

660703R1

FELT, spindle and doffer drive sprocket

1шт.

9/64 X 5/8" OV-HD SPLIT RIVET

6шт.
