Запчасти Case IH 414 (046) - DRUM DRIVE (14) - MAIN GEARBOX & DRIVE

1

666167R1

PULLEY, drum drive countershaft

2шт.

117979

KEY

5/16 X 1-1/8" WODRUFF KEY

2шт.

2

666536R91

SEAL

OIL SEAL, drum drive countershaft

4шт.

3

651818R91

ROLLER BEARING,31.77 mm ID x 16.08 mm

CONE, drum drive countershaft bearing

4шт.

4

651817R1

BEARING CUP

CUP, drum drive countershaft bearing

4шт.

5

666508R1

CARRIER, drum drive countershaft

2шт.

6

666176R1

EYEBOLT, drum drive

2шт.

1/4 X 1-1/4" COTTER PIN

2шт.

3/4 X 2-1/2" DLD HD PIN

2шт.

7

666177R1

TURNBUCKLE

drum drive clevis

2шт.

8

80710

LUBE NIPPLE,1/8” – 27 Dryseal PTF

NIPPLE, LUBE, 1/8"-27 x .66 lg

2шт.

9

666181R91

CLEVIS

drum drive stop

1шт.

1/4 X 1-1/4" COTTER PIN

1шт.

P14608

AXLE PIN

3/4 X 2-3/4" DLD HD PIN

1шт.

10

666184R91

EYEBOLT, drum drive trunnion

1шт.

1/4 X 1-1/4" COTTER PIN

1шт.

PO19594

PIN

3/4 X 1-1/2" DLD HD PIN

1шт.

11

666178R91

CLEVIS

drum drive

1шт.

7/8" NUT

2шт.

12

666173R91

LEVER, drum drive

1шт.

3/16 X 1-1/2" COTTER PIN

1шт.

13

666506R1

BRACKET, drum drive carrier left

1шт.

13

666507R1

BRACKET, drum drive carrier right

1шт.

3/8" JAM NUT

4шт.

222510

3/8 X 1-1/4" HEX-SOC-HD F-PT SET SCREW

4шт.

1/2 X 3" CAP SCREW W/NUT

4шт.

1/2" LOCK WASHER

4шт.

17/32 X 1" X 11 GA WASHER

4шт.

14

666505R1

PIN

drum drive carrier pivot

4шт.

1/2" NUT

4шт.

1/2" LOCK WASHER

4шт.

17/32 X 1" X 11 GA WASHER

4шт.

17/32 X 1" X 16 GA WASHER

4шт.

15

666234R91

YOKE

SHAFT W/YOKE

2шт.

7/8 NF SLOTTED NUT

2шт.

1/8 X 1-1/2" COTTER PIN

2шт.

PO12898

WASHER

29/32 X 1-1/2" X 11 GA WASHER

2шт.

16

661656R1

WASHER, cork

8шт.

17

661657R1

RING

SNAP RING

8шт.

18

661655R91

BEARING ASSY,0.59375" ID x 1.0625" OD x 0.4375"

8шт.

19

659262R91

U-JOINT SPIDER

KIT, cross service

2шт.

20

219-40

LUBE NIPPLE,65 Degree Elbow, 1/8" - 27 NPTF

lubrication

2шт.

21

666236R91

SHAFT, rectangular

2шт.

22

273354

SHEAVE

FITTING, lubrication

4шт.

23

666496R91

WASHER, shear bolt

2шт.

576517R1

LOCK PIN,1/4" x 1 1/2", Slotted

Pin, 1/4" x 1 1/2", Slotted

2шт.

24

665264R1

WASHER, shear bolt

2шт.

576517R1

LOCK PIN,1/4" x 1 1/2", Slotted

Pin, 1/4" x 1 1/2", Slotted

2шт.

25

665265R1

RING, thrust

2шт.

26

666500R91

YOKE FLANGED

2шт.

1/4 X 1-1/2" TYPE 2 CAP SCREW W/NUT (Shear bolt)

2шт.

1/4" LOCK WASHER

4шт.

27

659048R1

YOKE

2шт.

28

667267R91

SHAFT ASSEMBLY, rear half drive

1шт.

29

668342R91

SHAFT ASSEMBLY, front half drive

1шт.
