Запчасти Case IH 1822 (9-304) - OPERATORS PLATFORM SUPPORT (12) - CHASSIS

Схема запчастей Case IH 1822 - (9-304) - OPERATORS PLATFORM SUPPORT (12) - CHASSIS
28
14
27
6
27
37
5
32
3
27
31
38
44
36
26
26
21
8
13
42
28
9
38
28
39
2
25
20
32
17
14
27
28
27
16
1
26
40
6
28
26
15
26
19
13
37
4
25
10
27
29
26
41
30
43
28
7
26
8
15
27
43
3
27
4
16
33
28
39

Артикул

Название

Примечание

Количество

1

1270201C3

SUPPORT

CHANNEL - main cab support, left

1шт.

2

1270202C3

SUPPORT

CHANNEL - main cab support, right

1шт.

3

1278398C1

SUPPORT

- main side channel

2шт.

4

1270232C1

SUPPORT

CHANNEL - angle support

2шт.

5

1270231C3

CHANNEL

- horizontal cab support

1шт.

6

1270233C1

ANGLE BAR

ANGLE - channel support

2шт.

7

1270283C4

SUPPORT

- front angle

1шт.

8

1285275C1

SUPPORT

PIPE - cap support

2шт.

9

1270275C2

SUPPORT

- rear angle

1шт.

10

1278694C2

ANGLE

- platform eupport

1шт.

13

195507C6

SUPPORT

- operatcrs platform side

2шт.

14

196950C2

MOUNTING PARTS

INSULATOR - rear vibration

2шт.

15

117722C4

INSULATOR

- front vibration

2шт.

16

86867C1

BRACKET

- front mast

2шт.

17

87292C91

FUNNEL

FRAME ASSEMBLY - main

1шт.

19

68819C1

CAUTION DECAL

DECAL, CAUTION, Battery

1шт.

20

56630C1

PRODUCT GRAPHIC

DECAL - caution shields

1шт.

21

210600C1

DECAL

- danger repair and clean

1шт.

25

180173

BOLT,Hex, 1/2" - 13 x 1", Gr 5

20шт.

26

120384

WASHER,1/2"

LOCK, 1/2"

77шт.

27

120378

NUT,Hex, 1/2" - 13, Gr 5

NUT, 1/2"-13, G5

67шт.

28

180175

BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5

- hex, 1/2 NC x 1-1/4 inch

41шт.

29

180122

BOLT,Hex, 3/8" - 16 x 1", Gr 5

- hex, 3/8 NC x 1 inch

4шт.

30

120382

LOCK WASHER,Helical Spring, 3/8"

WASHER, LOCK, 3/8"

4шт.

31

120377

NUT,3/8" - 16, Gr 5

4шт.

32

180179

BOLT,Hex, 1/2" - 13 x 1 3/4", Gr 5

- hex, 1/2 NC x 1-3/4 inch

6шт.

33

413-1280

BOLT,Hex, 3/4" - 10 x 5", Gr 5

- hex, 3/4 NC x 5 inch , Course thraeds

2шт.

36

180177

BOLT,Hex, 1/2" - 13 x 1 1/2", Gr 5

- hex, 1/2 NC x 1-1/2 inch

8шт.

37

24771R1

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

4шт.

38

487374R1

BEARING LOCK NUT,Flg, USR, 1/2"-13

- hex flanged lock, 1/2 inch NC

8шт.

39

280954

NUT,3/4"-10, G5

4шт.

40

1317014C1

CARRIAGE BOLT,Short Sq Nk, 3/4" - 10 x 5", Type 5

BOLT - hex, 3/4 x 5 inch

2шт.

41

22184R1

WASHER

- flat, 1-5/32 x 1-5/8 x 3/64 inch

4шт.

42

478258R1

WASHER

- flat, 1-5/32 x 1-3/4 x 7/64 inch

2шт.

43

196591C1

WASHER

- isomount

4шт.

44

87037C1

BLOCK

SHIM - platform

1шт.

Выбрано товаров: 36
