Запчасти Case IH 1822 (6-18) - HYDROSTATIC PUMP, 1822 COTTON PICKER (03) - POWER TRAIN

Схема запчастей Case IH 1822 - (6-18) - HYDROSTATIC PUMP, 1822 COTTON PICKER (03) - POWER TRAIN
29
38
41
5
14
21
36
33
28
26
38
34
1
12
19
23
37
36
28
33
30
20
27
17
29
5
2
30
18
16
27
3
25
11
31
37
5
4
15
31
34
22
24
26

Артикул

Название

Примечание

Количество

1

1976869C1

PUMP

ASSEMBLY - hydrostatic, remanufactured (North America Only)

1шт.

1

1976870C1

CORE-HYDRAULIC PUMP

CORE ASSEMBLY - pump, (Use this number when returning pump core for credit)

1шт.

1

1976868C1

PUMP, HYDROSTATIC

PUMP ASSEMBLY - hydrostatic, new

1шт.

2

413-556

BOLT,Hex, 5/16" - 18 x 3-1/2", Gr 5

4шт.

3

REF

INSTRUCTION

PUMP - charge (See Page 6-33)

1шт.

4

133760C2

GASKET

- charge pump

1шт.

5

140754C1

PIN

- dowel, 51/6 x 5/8 inch

5шт.

11

NSS

NOT SOLD SEPARAT

COVER - end pump (Order 1976869C1)

1шт.

140760C91

SHIM KIT

- end cover (replaces 140783C91)

1шт.

12

NSS

NOT SOLD SEPARAT

SHIM - 0.003 inch

1шт.

12

NSS

NOT SOLD SEPARAT

SHIM - 0.005 inch

1шт.

12

NSS

NOT SOLD SEPARAT

SHIM - 0.010 inch

1шт.

12

NSS

NOT SOLD SEPARAT

SHIM - 0.015 inch

1шт.

12

NSS

NOT SOLD SEPARAT

SHIM - 0.020 inch

1шт.

12

NSS

NOT SOLD SEPARAT

SHIM - 0.030 inch

1шт.

14

140756C2

GASKET

- end cover

1шт.

15

28144R1

HEX SOC SCREW,#8 - 32 x 3/8"

SCREW, Hex Soc Hd, #8-32 x 3/8"

6шт.

16

140774C1

RETAINER

- servo piston

2шт.

17

NSS

NOT SOLD SEPARAT

HOUSNG PUMP - (Order 1976869C1)

1шт.

18

1288962C1

PLUG

- hex socket

1шт.

19

237-6004

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

4-1, 90 Duro, .351" ID x .072" Thk

1шт.

20

9410356

PLUG

- 1/4 inch straight thread o-ring boss

1шт.

21

237-6004

O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro

4-1, 90 Duro, .351" ID x .072" Thk

1шт.

142386C91

SHIM KIT

- trunnion bearing

1шт.

22

NSS

NOT SOLD SEPARAT

SHIM - 0.002 inch

6шт.

22

NSS

NOT SOLD SEPARAT

SHIM - 0.005 inch

4шт.

22

NSS

NOT SOLD SEPARAT

SHIM - 0.010 inch

4шт.

22

NSS

NOT SOLD SEPARAT

SHIM - 0.015 inch

4шт.

22

NSS

NOT SOLD SEPARAT

SHIM - 0.025 inch

4шт.

23

22409R1

O-RING,0.139" Thk x 2.609" ID, -231, Cl 5, 75 Duro

-231, 70 Duro, 2.609" ID x .139" Thk, trunnion

2шт.

24

NSS

NOT SOLD SEPARAT

TRUNNION - pump (Order 1976869C1)

2шт.

25

113-221

BOLT,Hex, 3/8" - 16 x 7/8", Gr 5

6шт.

26

140773C1

KIT

SLEEVE - servo

2шт.

27

383018R1

O-RING,2.675" ID x 0.103" Width

-147, 90 Duro, 2.675" ID x .103" Thk, servo sleeve

2шт.

28

22280R1

O-RING,0.103" Thk x 2.425" ID, -143, Cl 5, 75 Duro

- servo sleeve, 2-1/16 x 2-5/8 x 3/32 inch

2шт.

29

1980166C1

PISTON

ASSEMBLY - servo

2шт.

30

NSS

NOT SOLD SEPARAT

SCREW - hex socket

1шт.

31

NSS

NOT SOLD SEPARAT

RETAINER - servo spring

1шт.

33

NSS

NOT SOLD SEPARAT

SPRING - servo, heavy

1шт.

34

NSS

NOT SOLD SEPARAT

SPRING - servo, normal

1шт.

36

NSS

NOT SOLD SEPARAT

PIN - link

1шт.

37

NSS

NOT SOLD SEPARAT

RING - link retaining

2шт.

38

NSS

NOT SOLD SEPARAT

LINK - servo

1шт.

41

426-644

BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 8

6шт.

Выбрано товаров: 44
