Запчасти Case IH 1822 (9C-58) - BASKET INTERLOCK (16) - BASKET

1

87361C1

SUPPORT

BRACKET - roller pivot

1шт.

2

87342C3

ANGLE

BRACKET - switch activator

1шт.

3

667925R91

ROLLER BEARING,0.628" ID x 2" OD x 15 mm

ROLLER - interlock

1шт.

4

113-604

BOLT,Hex, 5/8" - 11 x 2", Gr 5

1шт.

5

129-107

NUT,5/8"-11, G5

1шт.

6

192-25

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

1шт.

7

87354C1

ANGLE

BRACKET - switch support

1шт.

8

REF

INSTRUCTION

SWITCH - interlock (See Page 4-15)

1шт.

9

REF

INSTRUCTION

MAST ASSEMBLY - basket (See Page 9C-51)

1шт.

10

21309R1

WASHER

- flat, 13/32 x 7/8 x 5/32 inch (1844 only)

1шт.

14

NSS

NOT SOLD SEPARAT

SPACER - tube, 1/2 inch (Order 196621C2, Serial Range: cut-length)

1шт.

15

113-122

BOLT,Hex, 5/16" - 18 x 1-1/2", Gr 5

1шт.

16

131-1215

LOCK NUT,5/16"-18, GC

NUT, LOCK, 5/16"-18, GC

1шт.

17

25710R1

WASHER

- flat, 11/32 x 1-1/16 x 5/64 inch

2шт.

18

495-11041

WASHER,0.406" ID x 0.812" OD x 0.065" W

- flat, 13/32 x 13/16 x 3/64 inch

1шт.

19

113-207

BOLT,Hex, 3/8" - 16 x 1", Gr 5

2шт.

20

192-21

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

21

129-103

NUT,Hex, 3/8" - 16, Gr 5

NUT, 3/8"-16, G5

4шт.

22

589068R1

WASHER

- flat, 21/32 x 1-1/4 x 3/32 inch

2шт.

23

495967R1

CARRIAGE BOLT,Short NK, 3/8"-16 x 1", G5, Full Thd

BOLT - round head square neck, 3/8 NC x 1 inch

2шт.
